- Page 1 TIG/INS10 TIGER POTTING SHED GENERAL ASSEMBLY INSTRUCTIONS...
-
Page 2: Before You Get Started
BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. - Page 3 Please retain instructions for future reference CAUTION: CAUTION: All buildings should be erected It is advisable to wear gloves by two competent adults. during building installation. MADE IN THE UK SINCE 1913. We have been making our high quality, great value garden buildings here in Britain for decades.
- Page 4 BEFORE YOU GET STARTED - PRE ASSEMBLY TOOLS REQUIRED: We recommend using the following tools (not supplied): HAMMER RUBBER MALLET LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW SPANNER FIXING KIT GUIDES: FX02 - NAIL KITS SMALL FX03 - NAIL KITS MEDIUM For Shed Products Up To 6ft Sides: For Shed Products With 7ft to 9ft Sides:...
- Page 5 Please retain instructions for future reference BUILDING PACK CONTENTS: For full details of what should be included please see the itemised packing list that is supplied with the delivery. They are also available on request in pdf form from our helpful Customer Support team – please call: 0113 205 4189 or use the “Items Delivered Query”...
- Page 6 TIGER POTTING SHED GENERAL INSTRUCTIONS Step 1: LAYING THE FLOOR • SINGLE FLOOR - Lay floor down in the desired position. (Detail A1) • MULTI FLOOR - 10x8 models. The bearers and floor boards may run in the opposite direction.
- Page 7 Please retain instructions for future reference Step 2: INSTALLING SIDE AND GABLE PANELS • Position one end gable and side panel as shown. (Detail B1) NOTE: CHECK THAT ALL PANELS ARE AT RIGHT ANGLES TO EACH OTHER AND THE FLOOR. •...
- Page 8 TIGER POTTING SHED GENERAL INSTRUCTIONS Step 3: SECURING SIDE AND GABLE PANELS • Locate pre-drilled holes in gable panels. (Detail C1) NOTE: THESE MAY HAVE COVERED OVER DURING PANEL COATING PROCESS. THEY MAY RESEMBLE NAIL HEADS. • Use 4x CB80 per gable, through the pre-drilled holes in each gable, from the outside.
- Page 9 Please retain instructions for future reference Step 3b: WINDOW FRAME INSTALLATION • Position the window frame in to place and securely fix this to the gables and lower front panel. • Secure through window frame using 3x N40 evenly spaced per edge. (Detail C4) •...
- Page 10 TIGER POTTING SHED GENERAL INSTRUCTIONS Step 4: SECURING SIDES PANELS TO THE FLOOR • Secure panels to the floor using 2x N65 per panel. Ensure the N65 are driven through the panels and into the floor bearers. (Detail D1) NOTE: PANELS HAVE BEEN REMOVED FOR CLARITY.
- Page 11 Please retain instructions for future reference Step 5: FIT BENCH • Fit the bench inside the shed, making sure you fit it underneath the frame as shown. • Nail upwards and secure using 2x N65 evenly spaced through the bench into the upright panel framing.
-
Page 12: Roof Installation
TIGER POTTING SHED GENERAL INSTRUCTIONS Step 6: ROOF INSTALLATION • Attach roof panels as shown. Ensuring that side with pre-fitted soffit board is to the high side. (Detail F1) • Fix roof to panels using N65 provided though roof boards into upright framing in panels. - Page 13 Each length of felt used is enough to cover the length CN13 of the roof plus overhang. Example: 6x6 Potting shed has the same roof size as a 6x4 Pent Shed and will be supplied with roll of felt to cover 12ft plus overhangs at each end.
- Page 14 TIGER POTTING SHED GENERAL INSTRUCTIONS Step 8: FITTING FASCIA BOARDS & FINIAL (BARGEBOARDS) • Fit bargeboards to the roof, trapping overhanging end of the felt in between the roof and bargeboard. • Secure using 2x N40 per bargeboard through roof.
- Page 15 Please retain instructions for future reference Step 10: INSTALLING GLAZING • Glaze windows by securing glass/styrene with PP25 supplied, from the inside. (Detail H) NOTE: ALL WINDOWS MUST BE SEALED INSIDE AND OUT WITH SILICONE, PUTTY, OR ANY OTHER WATER-TIGHT SOLUTION. (NOT SUPPLIED). •...
- Page 16 TIG/INS10 Display Agent Woodlands DIY Store Station Yard, Horsforth, Leeds, LS18 5NZ Telephone: 0113 205 4189 Website: tigersheds.com Email: customersupport@tigersheds.com...
