- Page 1 TIG/INS09 TIGER PENT BUILDINGS GENERAL ASSEMBLY INSTRUCTIONS...
-
Page 2: Before You Get Started
BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. - Page 3 We understand how busy life can be. Our Pro-Installation service can take the stress and strain out of assembling your quality Tiger building for you. We recommend using professional and dedicated installers to erect your building. With their knowledge and experience, they will ensure that your cabin is put properly in place ready for you to enjoy your space for years to come.
- Page 4 TIGER PENT BUILDING RANGE GUIDANCE: This guide provides assembly information for the Tiger Pent Building range. Images are for reference only and may vary from the product you have been supplied. If you have any issues, please contact your supplier.
- Page 5 Please retain instructions for future reference TIGER PENT TOOLSTORE TIGER PENT SHED TIGER PENTHOUSE TIGER PREMIUM TOOLSHED...
- Page 6 BEFORE YOU GET STARTED - PRE ASSEMBLY TOOLS REQUIRED: We recommend using the following tools (not supplied): HAMMER RUBBER MALLET LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW SPANNER FIXING KIT GUIDES: FX02 - NAIL KITS SMALL FX03 - NAIL KITS MEDIUM For Shed Products Up To 6ft Sides: For Shed Products With 7ft to 9ft Sides:...
- Page 7 Please retain instructions for future reference FX06 - NAIL KITS HEAVY DUTY For Heavy Duty Shed Products: CN13 Clout Nails (13mm Galvanised - QTY 450) PP25 Panel Pins (25mm - QTY 200) Nail (40mm Galvanised - QTY 85) Nail (65mm Bright - QTY 20) N100 Nail (100mm Bright - QTY 100)
- Page 8 TIGER PENT BUILDINGS - GENERAL ASSEMBLY INSTRUCTIONS Step 1: LAYING THE FLOOR • SINGLE FLOOR - Lay floor down in the desired position. (Detail A1) • MULTI FLOOR (excluding 10x8 & 12x8) - Lay floors down in the desired position and butt together.
- Page 9 Please retain instructions for future reference Step 2: INSTALLING SIDE AND GABLE PANELS • Position one end gable and side panel as shown. (Detail B1) NOTE: CHECK THAT ALL PANELS ARE AT RIGHT ANGLES TO EACH OTHER AND THE FLOOR. NOTE: CHECK ALL TRANSPORT BLOCKS HAVE BEEN REMOVED BEFORE FITTING PANELS.
- Page 10 TIGER PENT BUILDINGS - GENERAL ASSEMBLY INSTRUCTIONS Step 3: SECURING SIDE AND GABLE PANELS • Locate pre-drilled holes in gable panels. (Detail C1) NOTE: THESE MAY HAVE COVERED OVER DURING PANEL COATING PROCESS. THEY MAY RESEMBLE NAIL HEADS. • Use 4x CB80 per gable, through the pre-drilled holes in each gable, from the outside.
- Page 11 Please retain instructions for future reference • Secure panels to the floor using 2x N65 per panel. Ensure the N65 are driven through the panels and into the floor bearers. (Detail C4) NOTE: PANELS HAVE BEEN REMOVED FOR CLARITY. NOTE: FOR HD FRAMING BUILDINGS, USE N100. •...
- Page 12 TIGER PENT BUILDINGS - GENERAL ASSEMBLY INSTRUCTIONS Step 4: SINGLE PIECE ROOF INSTALLATION • Attach roof panels as shown. Ensuring that side with pre-fitted soffit board is to the high side. (Detail D1) • Fix roof to panels using N65 provided though roof boards into upright framing in panels.
- Page 13 Please retain instructions for future reference Step 4b: MULTI PIECE ROOF INSTALLATION • For roofs that come in multiple sections. Lift into place and butt together. (Detail D5) NOTE: CHECK OVERHANGS ARE EQUAL AT EACH END AND FRONT TO BACK. •...
- Page 14 TIGER PENT BUILDINGS - GENERAL ASSEMBLY INSTRUCTIONS Step 5: FELTING THE ROOF - MEASURE AND CUT BEFORE FITTING • Roll felt out onto a clean flat surface 30 minutes before you need it so it has a chance to flatten out.
- Page 15 Please retain instructions for future reference Step 6: FITTING FASCIA BOARDS & FINIAL (BARGEBOARDS) • Fit bargeboards to the roof, trapping overhanging end of the felt in between the roof and bargeboard. • Secure using 2x N40 per bargeboard through roof. NOTE: THERE ARE NO BARGEBOARDS SUPPLIED FOR LOW SIDE OF ROOF AS THIS WILL PREVENT EFFECTIVE WATER DRAINAGE.
- Page 16 TIGER PENT BUILDINGS - GENERAL ASSEMBLY INSTRUCTIONS Step 7: FIT CORNER STRIPS AND COVER STRIPS - CERTAIN SIZES ONLY • Secure the corner strips at each corner of the shed with 4x N40 per corner strip. NOTE: THESE CORNER STRIPS MAY NEED CUTTING TO SIZE.
- Page 17 Please retain instructions for future reference Step 8: INSTALLING GLAZING • Glaze windows by securing glass/styrene with PP25 supplied, from the inside. (Detail G) NOTE: ALL WINDOWS MUST BE SEALED INSIDE AND OUT WITH SILICONE, PUTTY, OR ANY OTHER WATER-TIGHT SOLUTION. (NOT SUPPLIED). NOTE: PLEASE DO NOT CONFUSE YOUR CORNER STRIPS WITH WINDOW BEADING.
- Page 18 TIGER PENT BUILDINGS - GENERAL ASSEMBLY INSTRUCTIONS Step 9: INSTALLING DOOR PULL • Find comfortable height for supplied door pull handle. • Secure handle to door using 4x 25mm (BS25) screws in the holes provided. • If door is made from interlocking boards and your chosen handle position does not match with existing door bracing, use supplied 150mm framing to fix handle screws into.
- Page 19 Please retain instructions for future reference • For summerhouse doors, secure directly into the door frame.
- Page 20 TIG/INS09 07/2024 Head Office TO VIEW GENERAL ASSEMBLY GUIDE FOR PENT ROOF SHED Calverley Lane, Rodley, Leeds, West Yorkshire, LS13 1NP Telephone: 0113 205 4189 Website: tigersheds.com Email: customersupport@tigersheds.com TO SEE GENERAL ACCESSORY & INSTALLATION VIDEO LIBRARY...
