  • Page 2 Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 This manual concerns the alternator AVR which you have just purchased. We wish to draw your attention to the contents of this maintenance manual. SAFETY MEASURES Before using your machine for the first time, it is important to read the whole of this installation and maintenance manual.
  • Page 3: Table Of Contents

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 CONTENTS 1 - POWER SUPPLY ....................... 4 1.1 - SHUNT excitation system ....................4 2 - R251 AVR ...........................5 2.1 - Characteristics ......................5 2.2 - U/F function and LAM ....................5 2.3 - AVR options ........................
  • Page 4: Power Supply

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 1 - POWER SUPPLY With a very simple conception, the SHUNT excitation alternator does not have a short 1.1 - SHUNT excitation system circuit capacity. The SHUNT excitation alternator is auto- The R251 is a R250 with a specific excita- excited with a R251 voltage regulator.
  • Page 5: R251 Avr

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 2 - R251 AVR The threshhold position and LAM function settings are done with the jumper. 2.1 - Characteristics - Storage: -55°C; +85°C Operating at 50 Hz: (U/F gradient) - Operation: -40°C;...
  • Page 6: Avr Options

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 2.3 - AVR options It is advised to use the “LAM” at 25% for load impacts > at 70% of the genset rated power. Potentiometer remote voltage adjustment, 1000 Ω...
  • Page 7: Typical Effects Of The Lam

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 2.5 - Typical effects of the LAM with a diesel engine or without a LAM (U/F only) 2.5.1 - Voltage Transient voltage drop (U/f) without LAM with Time 2.5.2 - Frequency Max speed drop...
  • Page 8: Installation - Commisioning

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 3 - INSTALLATION - 3.2.2 - Special type of use COMMISSIONING WARNING WARNING 3.1 - Electrical checks on the AVR - Check that all connections have been Excitation circuit E+, E- must not be left made properly as shown in the attached open when the machine is running: AVR...
  • Page 9: Electrical Faults

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 3.3 - Electrical faults Fault Action Effect Check/Cause The alternator builds up and its voltage is still correct when the - Lack of residual magnetism battery is removed The alternator builds up but its - Check the connection of the voltage Connect a new battery...
  • Page 10: Spare Parts

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 4 - SPARE PARTS 4.1 - Designation Description Type Code R251 AEM 110 RE 021 4.2 - Technical support service Our technical support service will be pleased provide additional information you may require.
  • Page 11: Disposal And Recycling Instructions

    Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251 Disposal and recycling instructions All materials listed above need special committed limiting treatment separate waste from environmental impact of our activity. We reclaimable materials and should be continuously monitor production...
  • Page 12 Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251...
  • Page 13 Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251...
  • Page 14 Installation and maintenance Electric Power Generation 4092 en - 2024.01 / g R251...
