- Page 1 USER’S MANUAL Round Propane Fire Pit Table NP10631WL-GR THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 ANS Z21.97 CSA 2.41-2017 Outdoor Decorative Gas Appliances INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. DANGER FIRE OR EXPLOSION HAZARD If you smell gas: Shut off gas to the appliance. Extinguish any open flame. If odor continues, leave the area immediately.
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION 1. The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable. - Page 4 13. This outdoor appliance is not for use on wood decks or other flammable surfaces. 14. Before each use of this gas appliance, open the door and/or the propane Tank Drawer and inspect the hose. If there is evidence of excessive abrasion or wear or if the hose is damaged, the hose assembly must be replaced prior to the appliance being put into operation.
-
Page 5: Specifications
3. The propane supply cylinder to be used must have a cylinder connection device compatible with the connection for the appliance. 4. A self-contained propane cylinder for use with this appliance must have a capacity of 20 Ibs cylinder (Height approximately 18 in., Tank Body approximately 12 in. -
Page 6: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY 1 pc 1 pc Weather cover Fire table 1 pc Lava rock 1 pack Door 1 pc Natural gas orifice 1 pc ASSEMBLY INSTRUCTIONS 1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product. - Page 7 CAUTION: Please be advised that this fire pit is equipped with natural lava rock that may crackle or pop the first time it is used. The lava rock has been pre-heat treated to release any natural inherent moisture. However, in rare cases on first time use, the lava rock may pop or burst causing small pieces of hot rock to potentially be a projectile.
- Page 8 black handle retention point Figure 3 4. Attach the door (C) with fire table (B) tenderly (See Figure 4). Figure 4 5. Once the firepit has cooled completely after use, carefully place the lid (A) onto the fire bowl and use the weather cover (D) to protect your fire pit from the elements (See Figure 5).
- Page 9 STOP STOP NATURAL GAS CONVERSION Natural gas conversion must be performed only by natural gas provider or a service company. 1. Disconnect the propane hose from the gas valve (see Figure 6). Caution: The propane tank shall be shut off prior to disconnecting the propane hose, before proceeding with the conversion.
- Page 10 4. Connect the natural gas hose to the gas valve by screwing clockwise tightly (see Figure 9). Plug the natural gas fixture into the natural gas supply system (see Figure 10). The conversion kit should be CSA certified. Below are several suggested CSA certified conversion kits for your reference.
- Page 11 Follow all warnings and instructions when using the appliance. tent, car or home. If part missing or damaged, or you need help with assembly, please do not hesitate to contact our customer service email us at cs.us@costway.com Figure 11 propane rating plate BATTERY Make sure the control knob is in the “OFF”...
- Page 12 LEAK TEST To prevent fire or explosion hazard when testing for a leak: 1. Always perform the leak test as described below before lighting this appliance or each time the cylinder is connected for use. 2. Do not smoke or allow other sources of ignition in the area while conducting a leak test.
-
Page 13: Lighting Instructions
2. Apply several drops of solution where the cylinder attaches to regulator, (see Figure 13), inspect the solution at the connection looking for bubbles. If NO bubbles appear, the connection is secure. If bubbles appear, the connection has the leak, disconnect the regulator, reconnect, perform another leak check. - Page 14 OFF ( A P G . ) gas control knob LIGHTING INSTRUCTIONS 1. Push in gas control knob slightly and turn to “OFF”. 2. Turn gas control knob to “ON/MIN”. 3. Push in gas control knob all the way and hold. Continue to press the ignition button for 15 seconds.
-
Page 15: Care And Maintenance
CARE AND MAINTENANCE To enjoy the outstanding performance from your fire pit, make sure you perform the following activities on a regular basis: 1. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents. 2. While cleaning the fire pit, make sure to keep the area around the burner dry at all times. - Page 16 With your inspiring rating, COSTWAY will be more consistent to offer you EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE! Mit Ihrer inspirierenden Bewertung wird COSTWAY konsistenter sein, um Ihnen EIN SCHÖNES EINKAUFSERLEBNIS, GUTE PRODUKTE und EFFIZIENTEN SERVICE zu bieten! Avec votre évaluation inspirante, COSTWAY continuera à...
