SMARTFOX PRO LIGHT 2 Operating Instructions Manual page 9

INSTALLATION OF THE SMARTFOX CURRENT
TRANSFORMER
CJG 441D 40A/I∆n0,03A G
L1 L2 L3 L1 L2 L3 N L2 L3 L1
L1 L2 L3
0 0 5 7 3 4 8
kWh
M13 0122
Attention! The SMARTFOX current transformers must always be connected as
shown in the picture above. (Arrows point in the direction of the consumer).
24V IO 0V
L1 L2 L3 N PE
Current
transformer
Energy meter
w w w . s m a r t f o x . at
0V + - PT1000
K K
R1
L L
L
K
L1 L2
V20-C V20-C V 2 0 - C
P H O T O V O
L T A I K
Post-counter field
Counter field
L L
K
KL3
Pre-counter field
7
