SCOPE OF DELIVERY & TECHNICAL
DATA
Scope of delivery
1x SMARTFOX Pro Light 2 energy consumption
controller 1x Micro SD card incl. adapter
1x current transformer 3-phase up to 80A | 100A incl.
connection set 1x operating manual
Technical data
Dimensions [W/H/D]
Rated current
4995A
Power supply
Self-consumption
Display
Analogue outputs
Switching output
Interface
Temperature input
Overload continuous
Surge overload
Connection
s
80A or via additional transformer
Voltage max. 265V, current 260A
L1/L2/L3/N/PE 3xL 1xN 1xPE 1.5mm²
Analogue output pluggable 24VDC/I+/GND
w w w . s m a r t f o x . at
98mm x 90mm x 58mm (5TE)
3 x 230V/400VAC 50Hz
2-line display
1 x 24VDC | 1 x 0/4-20mA
1 x normally open relay 5A/250VAC
Voltage 1000V 65μs
Converter Pluggable 1xRJ12 6pol.
4W
RS485
PT1000
1mm²
Relay 2x1,5mm²
