- Page 1 INSTALLATION GUIDE SEALED PELLET STOVE SUITE/CLUB/MUSA AIR 10 M3 SUITE/CLUB/MUSA COMFORT AIR 12 M PART 1 - REGULATIONS AND ASSEMBLY Translation of original instructions...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ....................II INTRODUCTION ......................1 1-WARNINGS AND WARRANTY CONDITIONS ..............2 2-INSTALLATION .......................11 3-DRAWINGS AND TECHNICAL SPECIFICATIONS ............19 4-UNPACKING ......................27 5-SUIT/CLUB STOVE ASSEMBLY ..................31 6-MUSA STOVE ASSEMBLY ..................46 7-DOOR OPENING .....................53 8-CONNECTIONS TO ADDITIONAL DEVICES ..............54 9-ELECTRICAL CONNECTION..................56 10-LOADING THE PELLETS ..................57... -
Page 3: Introduction
No part of this manual may be translated into other languages, adapted and/or reproduced, even in part, in other mechanical and/or electronic form or media, for photocopies, recordings or other, without the prior written authorisation of MCZ Group Spa. The company reserves the right to make changes to the product at any time without prior notice. The owner company reserves its rights according to law. -
Page 4: 1-Warnings And Warranty Conditions
1-WARNINGS AND WARRANTY CONDITIONS SAFETY WARNINGS • The installation, electrical connection, operating test and maintenance must only be carried out by a qualified operator. • Install the product in compliance with the laws and regulations in force. • Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. - Page 5 1-WARNINGS AND WARRANTY CONDITIONS • Do not dry laundry on the product. Any drying racks or the like must be kept at a safe distance from the product. Fire hazard. • The product maintenance operations must be exclusively carried out by a qualified operator on a yearly basis.
- Page 6 1-WARNINGS AND WARRANTY CONDITIONS • Do not allow the product to come into contact with water, it contains live electrical parts. • Do not wash the product with water (or other liquids) as they could penetrate inside the unit, damaging the electrical insulation with the risk of electrocution. • Do not use detergents to wash the stove, they could damage the aesthetic parts of the product.
- Page 7 1-WARNINGS AND WARRANTY CONDITIONS • The sound pressure level of this appliance does not exceed 70 dB(A). • Live electrical parts: only power the product once it has been fully assembled. • Disconnect the product from the 230V power supply before performing any maintenance operations.
- Page 8 1-WARNINGS AND WARRANTY CONDITIONS INFORMATION: • Please contact the retailer or qualified personnel for any information, problem or malfunction. • Only use the fuel specified by the manufacturer. • When the product is switched on for the first time, it is normal for it to emit smoke due to the paint heating up for the first time. Therefore make sure the room it is installed in is well-ventilated.
- Page 9 1-WARNINGS AND WARRANTY CONDITIONS WARRANTY CONDITIONS For the duration, terms, conditions, limitations of the MCZ conventional warranty, please refer to the specific warranty card that is included with the product. Information for management of waste electrical and electronic equipment containing batteries and accumulators This symbol appears on the product, on the batteries, on the accumulators or on their packaging or on their documentation;...
- Page 10 1-WARNINGS AND WARRANTY CONDITIONS WARNINGS FOR THE CORRECT DISPOSAL OF THE PRODUCT The owner is the sole party responsible for demolishing and disposing of the product. This must be performed in compliance with laws related to safety and environmental protection in force in his/her country. At the end of its working life, the product must not be disposed of as urban waste.
- Page 11 1-WARNINGS AND WARRANTY CONDITIONS LEGENDA WHERE TO DISPOSE MATERIALS Metal Glass If there is any, to be disposed of separately based on the material used: Tiles or ceramics OUTER CLADDING Stone Glass ceramic (fire door): to be disposed of with inert or mixed waste If there is any, to be disposed of separately based on the material used: Tempered glass (oven door): to be disposed...
- Page 12 The EC Declaration of Conformity, the Declaration of Performance required by EU Regulation 305/2011 and all other product certification documents can be downloaded by scanning the QR code on this page (also found on the product label) or by accessing the website page www.mczgroup.com/support/mcz Having specified the above, we highlight and report that: • This manual and technical data sheet, also available on our website, bear all of the specific indications and necessary and...
-
Page 13: 2-Installation
2-INSTALLATION The instructions in this chapter refer explicitly to the Italian installation regulation UNI 10683. In any case, always observe the regulations in force in the country of installation. PELLETS The pellet is obtained from natural dried wood sawdust (without paint). The compactness of the material is guaranteed by the lignin contained in the wood itself, without glue or binders. - Page 14 2-INSTALLATION FOREWORD The heating system (generator + combustion air supply + combustion product expulsion system + any hydraulic/aeraulic system) must be installed in compliance with the laws and regulations in force , and carried out by a qualified technician, who must issue a declaration of conformity of the system to the system manager and shall undertake full responsibility for final installation and consequent good operation of the product.
- Page 15 2-INSTALLATION MINIMUM DISTANCES Observe the distances from flammable objects (sofas, furniture, wood panelling, etc..) as specified in the following diagram. If objects considered to be particularly sensitive to heat are present, such as furniture, curtains or sofas, as a precaution, increase the stove clearances substantially to avoid possible deterioration due to the effect of heat.
- Page 16 2-INSTALLATION In any case, ensure adequate distance to facilitate access during cleaning and extraordinary maintenance. If this is not possible, it must still be possible to distance the product from adjacent walls/elements. This operation must be performed by a technician qualified to disconnect the combustion product expulsion ducts and their subsequent restoration.
- Page 17 2-INSTALLATION Below 15kW: Air duct diameter Maximum length Maximum length (smooth duct) (corrugated duct) 50mm 60mm 80mm 100mm Above 15kW: Air duct diameter Maximum length Maximum length (smooth duct) (corrugated duct) 50mm 60mm 80mm 100mm Technical Dept. - All rights reserved - Reproduction prohibited...
- Page 18 2-INSTALLATION Preparing the smoke expulsion system The combustion product expulsion system is a particularly important element for the proper operation of the appliance and must be correctly sized according to EN 13384-1. Its creation/adaptation/verification must always be carried out by a legally qualified operator and must comply with the regulations in force in the country where the appliance is installed.
- Page 19 2-INSTALLATION Chimneypot The chimneypot, meaning the end part of the flue, must meet the following characteristics: • the smoke outlet section must be at least double the internal section of the chimney; • prevent the penetration of rain or snow; •...
- Page 20 2-INSTALLATION EXAMPLES OF INSTALLATION (DIAMETERS AND LENGTHS TO BE SIZED) 1. Flue installation with hole for the passage of the pipe increased by: • minimum 100mm around the pipe if next to non-flammable parts such as cement, brick, etc.; or •...
-
Page 21: 3-Drawings And Technical Specifications
3-DRAWINGS AND TECHNICAL SPECIFICATIONS DRAWINGS AND CHARACTERISTICS SUITE/CLUB AIR 10 M3 STOVE DIMENSIONS Ø50 Ø80 Technical Dept. - All rights reserved - Reproduction prohibited... - Page 22 3-DRAWINGS AND TECHNICAL SPECIFICATIONS SUITE/CLUB COMFORT AIR 12 M3 STOVE DIMENSIONS...
- Page 23 3-DRAWINGS AND TECHNICAL SPECIFICATIONS MUSA AIR 10 M3 STOVE DIMENSIONS Ø50 Ø80 Technical Dept. - All rights reserved - Reproduction prohibited...
- Page 24 3-DRAWINGS AND TECHNICAL SPECIFICATIONS MUSA COMFORT AIR 12 M3 STOVE DIMENSIONS Ø50 Ø80...
- Page 25 3-DRAWINGS AND TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS SUITE/CLUB/MUSA AIR 10 M3 Energy Efficiency Class Nominal output power 10.0 kW (8600 kcal/h) Minimum power output 3.5 kW (3010 kcal/h) Efficiency at Max 90.4% Efficiency at Min 91.5% Temperature of exhaust smoke at Max 212 °C...
- Page 26 3-DRAWINGS AND TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS SUITE/CLUB/MUSA COMFORT AIR 12 M3 Energy Efficiency Class Nominal output power 11.9 kW (10234 kcal/h) Minimum power output 3.9 kW (3354 kcal/h) Efficiency at Max 90.8% Efficiency at Min 93.5% Temperature of exhaust smoke at Max 193 °C Temperature of exhaust smoke at Min 86 °C...
- Page 27 3-DRAWINGS AND TECHNICAL SPECIFICATIONS INFORMATION REQUIREMENTS FOR SOLID FUEL LOCAL SPACE HEATERS ACCORDING TO COMMISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) MCZ GROUP SpA Manufacturer: Trademak: Model Identifier: SUITE AIR 10 M3 / CLUB AIR 10 M3 / MUSA AIR 10 M3...
- Page 28 INFORMATION REQUIREMENTS FOR SOLID FUEL LOCAL SPACE HEATERS ACCORDING TO COMMISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) Manufacturer: MCZ GROUP SpA Trademak: Model Identifier: SUITE COMFORT AIR 12 M3 / CLUB COMFORT AIR 12 M3 / MUSA COMFORT AIR 12 M3...
-
Page 29: 4-Unpacking
4-UNPACKING INSTRUCTIONS FOR PACKAGING DISPOSAL The material that the appliance’s packaging is made of must be managed correctly, in order to make collection, reuse, recovery and recycling easier, where possible. The table below illustrates the possible components that the packaging is made of, and the relative instructions for correct disposal. DESCRIPTION CODE MATERIAL SYMBOL... - Page 30 4-UNPACKING Handle the product with suitable means paying attention to the applicable safety regulations in force. Do not turn the packaging over and handle the majolica parts with care. The stoves are delivered in a single package with ceramic panels packaged together with the structure and placed on top or, in the case of metal panels, inside the pallet with the structure.
- Page 31 4-UNPACKING REMOVING THE FASTENING BRACKETS (SUITE/CLUB STOVES) To remove the SUITE/CLUB/MUSA stove from the pallet, you must remove the two screws “u” and plate “s” from the stove’s foot. There are four brackets “s”. REMOVING THE FASTENING BRACKETS (MUSA STOVE) Technical Dept.
- Page 32 4-UNPACKING Position the stove and connect it to the flue. Use the 4 adjustable feet (J) to get the stove correctly levelled so that the smoke outlet is lined up with the connecting pipe. If the stove needs to be connected to an outlet pipe which goes through the rear wall (to connect to the flue), take the utmost care to make sure that the joint is not forced.
-
Page 33: 5-Suit/Club Stove Assembly
5-SUIT/CLUB STOVE ASSEMBLY Live electrical parts: only power the product once it has been fully assembled. On delivery, the Suite and Club stoves have no ceramic cladding, as shown in the image below. Take the box with the ceramics (figure below) and prepare them for installation. The ceramics are already completely assembled (ceramics and mounting brackets) and must be mounted as per the attached diagram, “Side panels assembly”... - Page 34 5-SUIT/CLUB STOVE ASSEMBLY INSTALLING THE SIDE PANELS There are codes on the internal part of the ceramics to help correctly position them. As shown in the following image, on the right side they are called D1/D2/D3 and on the left side S1/S2/S3, to be placed from the bottom upwards.
- Page 35 5-SUIT/CLUB STOVE ASSEMBLY REMOVING THE CERAMIC PANELS FASTENING FRAME Remove the two screws “x” and the two notched washers “z” from the top part. Attention! The two screws “x” and the two notched washers “z” must be used again to secure the frame with the ceramic panels.
- Page 36 5-SUIT/CLUB STOVE ASSEMBLY Make the holes “V” of the frame “S” come out from the hooks “L” on the structure of the stove.
- Page 37 5-SUIT/CLUB STOVE ASSEMBLY Take the template “U” from the structure’s packaging, which must be used to position the ceramic panels correctly. The part of the template marked “FRONT RIGHT” must be positioned as indicated in the picture, towards the front part of the stove. Use the two screws “k”...
- Page 38 5-SUIT/CLUB STOVE ASSEMBLY From the ceramic panels packaging, take the three ceramic panels marked “D1”, “D2”, “D3”. Place a sheet or cloth on the floor “T” to avoid scratching or damaging the ceramic panels during assembly. Place the three ceramic panels on the sheet “T” on the floor, as indicated in the picture. Take the frame “S”...
- Page 39 5-SUIT/CLUB STOVE ASSEMBLY Now, take the 12 screws “m” and 12 washers “n” from the ceramic panel package. Secure the frame “S” to the ceramic panels using the screws “m” and washers “n”. After securing the frame/ceramic panels, remove the two screws “k” and remove the template “U”. Technical Dept.
- Page 40 5-SUIT/CLUB STOVE ASSEMBLY Lift the three ceramic panels with the frame and secure it to the stove’s structure. At the bottom, insert the holes “V” on the frame of the ceramic panels into the hooks “L” fitted on the structure of the stove.
- Page 41 5-SUIT/CLUB STOVE ASSEMBLY On the top, secure the frame to the structure with the two screws “x” and notched washers “z” that were previously removed with the frame “S”. Attention! The frame with the ceramic panels has slotted holes “f” to adjust the ceramic panels with the front parts of the stove.
- Page 42 5-SUIT/CLUB STOVE ASSEMBLY Repeat the same operation also for the ceramic panels marked “S1”, “S2”, “S3”.
- Page 43 5-SUIT/CLUB STOVE ASSEMBLY INSTALLING THE FRONT LOWER CERAMIC PANEL Remove the two screws “j” from the structure of the stove and remove the bracket “O”. Take the ceramic panel “B” from the package of the ceramic panels. Remove the M4x16 screw “g” from the lower part of the bracket “O”. Technical Dept.
- Page 44 5-SUIT/CLUB STOVE ASSEMBLY Insert the bracket “O” into the frame of the ceramic panel “B” and secure it in the lower part with the screw “g” you have just removed. Now secure the ceramic panel “B” to the structure of the stove using the two screws “j”.
- Page 45 5-SUIT/CLUB STOVE ASSEMBLY ADJUSTING THE LOWER PANEL It is possible to adjust the magnet “r” from the screw “v”. Then, try to bring the ceramic panel “B” flush with the door of the firebox by adjusting the magnet “r”. Technical Dept. - All rights reserved - Reproduction prohibited...
- Page 46 5-SUIT/CLUB STOVE ASSEMBLY ASSEMBLING THE TOP At this point, the side panels are assembled, as well as the lower panel. Before proceeding with placing the top “A”, perform a final check of the position of the side panels. Make sure they are in line with the front panels and the door. If necessary, adjust them from the slots on the frame of the side ceramic panels.
- Page 47 5-SUIT/CLUB STOVE ASSEMBLY REMOVING THE UPPER PANEL Panel “F” is already fixed to the stove structure, it may be removed in the event of maintenance, servicing or cleaning. After removing any top, remove screws “k”, two on the right and two on the left, and remove the top front panel “F”. Technical Dept.
-
Page 48: 6-Musa Stove Assembly
6-MUSA STOVE ASSEMBLY Live electrical parts: only power the product once it has been fully assembled. On delivery, the MUSA stove has no metal cladding and has the top fitted, as shown below. Take the box with the metal sides and prepare them for installation. The sides are fitted with screws for fixing to the structure. STOVE STRUCTURE METAL CLADDING Caution! Carefully handle the metal sides as the paint might be damaged. - Page 49 6-MUSA STOVE ASSEMBLY REMOVING THE TOP Removal of the top is not required for assembling the metal sides. It can be removed for servicing or any needs and if required, to assemble the sides more easily. Lift the pellet cover “W”, remove the two screws “x” and remove the complete top “G”.
- Page 50 6-MUSA STOVE ASSEMBLY ASSEMBLING THE METAL SIDES Mount the metal sides by proceeding as follows: • Pre-fasten on the stove structure the washer “n” and the screw ”m” in the part below the top. • After inserting the panel in the lower part of the stove (see next page) move panel “E” close to the structure so that the slots “p” house the screw “m”...
- Page 51 6-MUSA STOVE ASSEMBLY At the bottom, insert the hooks “z” fitted on the structure of the stove into the holes “v” on the side metal panel. Technical Dept. - All rights reserved - Reproduction prohibited...
- Page 52 6-MUSA STOVE ASSEMBLY From above, through the slot on the top, tighten screw “m” which has been secured to the structure before.
- Page 53 6-MUSA STOVE ASSEMBLY In the event of assembling the panels without the top, fasten the sides to the structure from above by means of washer “n” and screw “m”. Technical Dept. - All rights reserved - Reproduction prohibited...
- Page 54 6-MUSA STOVE ASSEMBLY Proceed with the other side “E” in the same way.
-
Page 55: 7-Door Opening
7-DOOR OPENING OPENING THE DOOR OF THE FIREBOX To open the firebox door “F”, insert the cold handle “Z” into the hole in the handle “P” and pull it towards you. Attention! Only open the door when the stove is off and cold. OPENING THE DOOR OF THE FIREBOX LOWER DOOR OPENING LOWER DOOR OPENING... -
Page 56: 8-Connections To Additional Devices
8-CONNECTIONS TO ADDITIONAL DEVICES Comfort Air ducting Comfort Air stoves can channel the air into other rooms through the connection with the accessory pipes to the rear “S” shaped flange provided as per standard. The recommended maximum duct length is 8 metres per fan. It is advisable to set up ducts of similar length to distribute the hot air evenly in the various rooms. - Page 57 8-CONNECTIONS TO ADDITIONAL DEVICES Attention! It is mandatory to install the vents with “V” netting (1 or 2 depending on the type of appliance) on the rear “S” output for safety purposes and to prevent the rear wall from being hit directly by the hot air flow, generating halos, blackening or even dangerous heating in the case of flammable walls.
-
Page 58: 9-Electrical Connection
9-ELECTRICAL CONNECTION ELECTRICAL CONNECTION First connect the power cable to the back of the stove and then to a wall socket. It is recommended to disconnect the power cable when the stove is not used. ELECTRICAL STOVE CONNECTION The cable must never come into contact with the smoke exhaust pipe or any other part of the stove. STOVE POWER SUPPLY Connect the power cable to the back of the stove and then to a wall socket. -
Page 59: 10-Loading The Pellets
10-LOADING THE PELLETS LOADING THE PELLETS Fuel is loaded from the upper part of the stove by lifting door “W”. Pour the pellets in slowly so that they are deposited at the bottom of the hopper. If loading pellets when the stove is running, open the door of the tank using the cold handle that comes with the stove itself. - Page 60 MCZ GROUP S.p.A. Via La Croce n°8 33074 Vigonovo di Fontanafredda (PN) – ITALY Telephone: 0434/599599 a.s. Fax: 0434/599598 Website: www.mcz.it e-mail: mcz@mcz.it 8902258000 REV.0 22/11/2022...
