- Page 1 User manual EasyLift V3 PLUS USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Liftup A/S | Hagensvej 21 | DK-9530 Støvring | Danmark | T: +45 96 86 30 20 | M: support@liftup.dk | www.liftup.dk | CVR: DK-1015 3964...
-
Page 2: Table Of Contents
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Contents Foreword ..........................4 Declarations ........................... 5 2.1 Regulatory Approvals ......................8 2.2 EU declaration of conformity .................... 9 Factory Acceptance Test (FAT) .................... 10 Terms of use ........................11 Technical specifications ....................... - Page 3 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 13.1 Wireless call station/call station column 2.4 GHz ............31 13.2 Remote control 2.4 GHz (optional equipment) .............. 33 14. Installation and handover....................35 15. Inspection, checks and service inspections ................. 36 15.1 Statutory inspection and checks ..................
-
Page 4: Foreword
1. Foreword Congratulations on purchasing your new EasyLift lifting platform. This is an original user manual for your new EasyLift V3 PLUS. Hereinafter we use the term EasyLift for EasyLift V3 PLUS, if nothing else is specifically indicated. It is important to read this manual before using the lift Set-up and installation MUST be undertaken by a qualified Liftup service technician, to ensure correct assembly. -
Page 5: Declarations
Resellers who purchase the EasyLift V3 PLUS product (“Product”) directly from Liftup: for a period of one (1) year from the date of shipment from Liftup, the Product will substantially conform to Liftup’s standard published specifications for the Product and the Product hardware will be substantially free from defects in materials and workmanship. - Page 6 Product with hardware or software products, information, data, systems, interfaces, services or devices not made, supplied or specified by Liftup; (b) the operation of the Product under any specifications other than, or in addition to, Liftup’s standard published specifications for the Product;...
- Page 7 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 APPLICABLE LAW, IN NO EVENT SHALL LIFTUP OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER UNDER CIRCUMSTANCE OR LEGAL THEORY RELATING IN ANY WAY TO THE PRODUCTS, ACCOMPANYING...
-
Page 8: Regulatory Approvals
Regulatory Approvals FCC/IC The radio module contained in the EasyLift V3 PLUS and associated remote comply with the FCC Part 15.249 and the Industry Canada requirements RSS-GEN, RSS-210 The radio module contained in the EasyLift V3 PLUS and associated remotes complies with Part 15 of the FCC rules and with Industry Canada license exempt standard(s). -
Page 9: Eu Declaration Of Conformity
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 EU declaration of conformity Manufacturer: Liftup A/S Address: Hagensvej 21, DK-9530 Støvring, Denmark Telephone: +45 9686 3020 hereby declares that: EasyLift V3 PLUS Equipment: Lifting platform for wheelchair users and persons with impaired... -
Page 10: Factory Acceptance Test (Fat)
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 3. Factory Acceptance Test (FAT) Liftup A/S Hagensvej 21 | DK-9530 Støvring | Danmark | +45 96 86 30 20 | support@liftup.dk | www.liftup.dk | CVR: DK-1015 3964... -
Page 11: Terms Of Use
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 4. Terms of use The lift is exclusively for the use of wheelchair users and persons with impaired mobility. It is important to read this manual before using the lift IMPORTANT! The lift must NOT be used for goods transport, including loaded pallets or other types of heavy loads. -
Page 12: Technical Specifications
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 5. Technical specifications EasyLift 800/900 V3 PLUS EasyLift 1100 V3 PLUS All scale drawings for EasyLift V3 PLUS are available at Liftup Product Configurator: https://config.liftup.dk/ Specifications: Power: 90 – 305V-AC / 1,67 A / 60 W... - Page 13 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Lifting speed/ temperature: in/sec mm/sec +40 ˚C - +5 ˚C: +104 - 41 1.57” 40 mm +5 ˚C - -5 ˚C: - 23 0.79” 20 mm -5 ˚C - -20 ˚C: - -4 0.39”...
- Page 14 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Wall-mounted wireless call station (REMOTE2) 2,4 GHZ Short Range devices FCC ID: 2AK8H-REMOTE2 Receiver Class 3 Dimensions (L x W x H): 170 x 72 x 42mm / 6.70 x 2.83 x 1.65 in.
-
Page 15: Safety Instructions
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 6. Safety instructions Installation, handling and repair Do not attempt to install or repair the lift yourself. This MUST be done by an authorized service technician. Do NOT remove the protective plates or safety plates, as this could lead to the lift causing personal injury. -
Page 16: Overload Of The Lift
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Overload of the lift In order to avoid damage to equipment due to overloading (max. 750 lbs/340 kg (EasyLift 800/900 V3 PLUS) or 880 lbs/400 kg (EasyLift 1100 V3 PLUS) evenly distributed), the lift is fitted with overload protection which stops the lift and issues an audible alarm if overload occurs. -
Page 17: Safety Barriers
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Safety barriers 6.8.1 Ramp as roll-off protection If the lift is fitted with a ramp, the ramp will first pull up and lock before the lift begins to move. The ramp now acts as roll-off protection. When the lift returns to floor level, the ramp will automatically lower (keep the button pressed) and act as a drive-on/drive-off ramp. -
Page 18: Lifts Accessible To The Public (Only Certain Countries)
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 6.8.3 Automatic doors (optional equipment) If the lift is fitted with automatic doors, they will close, and the door motor will be in a locked position before the lift starts to move. The doors will always be closed when the lift has moved off ground level. -
Page 19: Breakdown/Malfunction
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 6.10 Breakdown/malfunction 6.10.1 Unlocking the vertical barrier in an emergency In the event of an emergency/breakdown: Slowly press down the barrier. WARNING! If you push too quickly, the barrier motor may be ruined. - Page 20 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 4. When the spring is released pull out the bolt. NOTE: The bolt may be difficult to pull out, because of pressure on the door actuator. 5. Now the door can be moved freely 6.
-
Page 21: Function Description
These actions MUST be performed by an authorized service technician. Improper assembly may increase the risk of user injury. Liftup is exempt from any liability if assembly and installation are not performed by an authorized service technician. -
Page 22: Start-Up
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 9. Start-up The lift must always be connected to a 100-240V power point and be powered on. Under normal circumstances the lift is always in stand-by mode, i.e. it is ready for use as soon as one of the operating buttons is pressed. -
Page 23: Operating The Lift From The Upper Level
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Fig. 6: Fig. 7: Fig. 8: Fig. 9: Call station column Call station column Call station column Call station column with cable, 1-way with cable, 2-way wireless, 1-way wireless, 2-way Fig. -
Page 24: Operating The Lift From The Lower Level
You can now exit the lift. 10.5 Auto return The auto return function can be activated by an authorized service technician via the Liftup Service Tool. IMPORTANT! Your authorized service technician can ascertain whether the automatic operation of the lift is permitted, depending on the legislation in the country in question. -
Page 25: Emergency Stop
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 10.6 Emergency stop If the lift makes an unintended or undesired movement, or if it must be stopped in order to avoid potential risks, press the EMERGENCY STOP button. To release the emergency stop, turn the button clockwise and the system is again ready for use. -
Page 26: Audible Alarms
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 10.8 Audible alarms Speak Activity/warning Opening The vertical safety barrier is opening Closing The vertical safety barrier is closing Alarm: Overload alarm The platform is overloaded The battery has a fault. Inadequate power Alarm: Battery fault –... -
Page 27: Alarm And Emergency Call
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 10.9 Alarm and emergency call The lift can be equipped with an alarm button (optional equipment) that can summon assistance. In order to activate the alarm, press on the alarm button and hold it in for approx. -
Page 28: Operation
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 11. Operation Under normal operating conditions the lift shall always be connected to 100-240V. It is very important that the power is not disconnected or switched off, as long-standing power outage (10-20 hours) may result in flat batteries and thus inoperability. -
Page 29: Maintenance
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 12. Maintenance Clean by wiping off with a cloth that has been wrung out in water containing a mild detergent. IMPORTANT! Do NOT use a high-pressure cleaner or wash the lift down with water straight from a hose. - Page 30 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 How to replace the battery: Hand-held remote control 1. Loosen the screw ( Torx TX 6) on the rear of the remote control 2. Remove the rear panel 3. Replace the battery 4.
-
Page 31: Pairing Transmitter And Receiver
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 13. Pairing transmitter and receiver 13.1 Wireless call station/call station column 2.4 GHz The transmitter and receiver must always be paired in order to work. This is normally done at the factory or by an authorized service technician. - Page 32 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 4. The printed circuit containing the trans- mitter is now visible and should be briefly pressed at S4 in order to pair it with the receiver (must be done within 2 minutes).
-
Page 33: Remote Control 2.4 Ghz (Optional Equipment)
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 13.2 Remote control 2.4 GHz (optional equipment) The transmitter and receiver must always be paired in order to work. This is normally done at the factory or by an authorized service technician. The receiver will not respond to a transmitter without it having been paired with the receiver. - Page 34 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 To reset a remote control so that it is no longer paired, the following points should be followed: How to reset the transmitter: 1. Press the Up (↑) and DOWN (↓) buttons at the same time for 5 seconds until the control LED on the remote control starts to flash slowly.
-
Page 35: Installation And Handover
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 14. Installation and handover The installation and handover check list below, which lists the lift's operating and safety functions, must be gone over with the user/owner of the lift before installation is concluded. -
Page 36: Inspection, Checks And Service Inspections
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 15. Inspection, checks and service inspections In addition to the general maintenance described in section 12, regular service inspections and statutory checks and inspections of the lift must be carried out. -
Page 37: Service Report For Use In Service Inspections
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 15.3 Service report for use in service inspections Liftup A/S Hagensvej 21 | DK-9530 Støvring | Danmark | +45 96 86 30 20 | support@liftup.dk | www.liftup.dk | CVR: DK-1015 3964... -
Page 38: Service Logbook
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 15.4 Service logbook The form (like the example below) must be completed after each inspection. Liftup A/S Hagensvej 21 | DK-9530 Støvring | Danmark | +45 96 86 30 20 |... -
Page 39: Online Service Log (Only Certain Countries)
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 15.5 Online service log (only certain countries) With a smart phone, tablet or similar, the QR code can be scanned. The QR code can be found on the label placed on the left side frame: The CE label inserted in section 3 will provide you with the serial number of the specific lift as well as its QR code with direct access to the online service log. -
Page 40: Spare Parts And Accessories
USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 16. Spare parts and accessories IMPORTANT! It is important to use only original spare parts. Replacement of parts may only be undertaken by an authorized service technician. The use of non-original spare parts may void the right of complaint. - Page 41 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Description Illustration Article No. Actuator for door 102355 EasyLift 800/900 (black) 104179 EasyLift 1100 (black) Cable for vertical barrier/ 101558 call station Remote control 103933 – transmitter unit (accessory) Repair spray,...
- Page 42 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Description Illustration Article No. 103080 Power supply unit 36 V Actuator Complete, motor 103182 EasyLift V3 Spring for ramp 103152 - Friction clutch Programming Cable USB A to B 103333...
-
Page 43: Disassembly
The right of complaint encompasses the at any time applicable rules regarding the right of complaint. Liftup offers full right of complaint on spare parts for two years provided the product is registered with Liftup (http://lpr.liftup.dk/). Liftup A/S Hagensvej 21 | DK-9530 Støvring | Danmark | +45 96 86 30 20 | support@liftup.dk | www.liftup.dk | CVR: DK-1015 3964... - Page 44 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Please read more about this in the terms of sale and delivery: https://www.liftup.dk/en/about-liftup/general-conditions/ NOTE: If the prescribed service inspections are not maintained, the right of complaint may be lost.
- Page 45 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ Liftup A/S Hagensvej 21 | DK-9530 Støvring | Danmark | +45 96 86 30 20 | support@liftup.dk | www.liftup.dk | CVR: DK-1015 3964...
- Page 46 USER MANUAL – EASYLIFT V3 PLUS – AU VERSION 09.02 Liftup A/S Hagensvej 21 | DK-9530 Støvring | Danmark | +45 96 86 30 20 | support@liftup.dk | www.liftup.dk | CVR: DK-1015 3964...
