Rating Plate; Technical Data - SFA Sanipit Manual

- flammable or explosive liquids such as oil, gasoline, kerosene, ethanol,
etc.,
- waste water containing harmful substances, e.g. untreated grease
water from restaurants. These require the installation of a grease trap.
DANGER
Pumping unauthorized fluids
Danger for the people and the environment.
Ö Only discharge authorized pumped fluids in the public
sewage network.
All applications other than those described in this manual are pro-
hibited.
3.2 OPERATING PRINCIPLE
The waste water (effluent) flows into the sewage pumping station by
gravity and enters the tank through the side inlet (1 inlet on 24GRCB).
It accumulates in the plastic tank, which is watertight and designed for
non-pressure operation.
The effluent level rises in the tank and the dip tubes. When the acti-
vation level is reached in the long dip tube, the level sensor and the
associated control box activate the pump, which grinds and pumps the
water out of the tank via the discharge line. A non-return valve in the
discharge line prevents backflow into the tank.
The vent line ensures that the tank always remains at atmospheric pres-
sure.
In case of abnormal operation, if the effluent reaches the alarm level in
the tank (short tube), the audible and visual alarm of the control box is
activated and the pumping system starts (if not faulty).
3.3 SCOPE OF SUPPLY
Sanipit sewage pumping stations are supplied with:
– a cover (not suitable for pedestrian traffic),
– a seal,
– 3 screws and washers for the cover,
– a support for pressure switch (level sensors and dip tubes) and
grinding pump,
– 16 screws and washers for the support,
– an external control box,
– a wired alarm system,
– 2 connecting sleeves for inlet and vent piping,
– 1 connecting sleeve with a built-in non-return valve for discharge pip-
ping,
– 6 clamps for the connecting sleeves.
Sanipit 24GRCB:
– a 39 gal (148 L) basin.

3.4 RATING PLATE

Sewage pumping station
SFA SANIFLO INC.
105 New eld Avenue. Suite A
EDISON. NEW JERSEY 08837
Tel: 732-225-6070 Fax : 732-225-6072
8
Duty Cycle : 4,8 sec ON/18 sec OFF
Model : SANIPIT24GRCB
7
1 Voltage
2 Frequency
3 Maximum current consumption
4 Date of production
5 Identification number
6 Certification
7 Model of the sewage pumping station
8 Mode of operation
9 Company details
Control Box
1
CONTROL BOX
SANIPIT
6
SFA
MADE IN FRANCE
1 Name of the control box
2 Voltage
3 Phase type
4 Frequency
5 Date of production
6 Connected sewage pump station

3.5 TECHNICAL DATA

Motor
Voltage
1
AC 120V
Thermally Protected
2
60 Hz
10 A
3
N°226615
4
JULY-2023
ASMS A112.3.4/CSA B45.9
N°007
6 5
2 3
4
AC 120 V 1~ 60Hz
5
14/06/2023
SANIPIT
1 HP oil-filled thermally protected motor
120 V
Frequency
Maximum current consumption
IP rating
Capacitor rating
Maximum vertical discharge
Maximum horizontal discharge
Flow rate (at 10 ft)
Shut-off head
Max temp with intermittent
functioning (5 min. max.)
Normal running time
Cable Station-Control Box
Cable Control Box-Mains
Discharge pipe diameter
Ventilation diameter
Sanipit 24GRCB
Inlet diameter
ON/OFF Level
Alarm Level
3.6 PERFORMANCE CURVE
Flow rate (L/min)
0 50 100
35
30
25
20
15
10
5
0
0 10 20 30
Flow rate (gal/min)
3.7 DIMENSIONS
See page 3.
3.8 DESIGN
3.9 EXTERNAL CONTROL BOX
Pump control and monitoring unit integrated in a box with power and
alarm indicators, and forced operation button.
3.9.1 Electrical data
PARAMETER
Voltage
Frequency
IP rating
3.9.2 Technical data of the detection device
Analog level sensor Input voltage: 0 - 5 V
Process output One signalling output for the wired alarm unit: 12V
3.9.3 Dimensions
5
SANIPIT
60 Hz
10 Amps
IP 68
60 μF
25 ft (7.2 m)
328 ft (100 m)
57 gpm (13 m /h)
3
33 ft (10 m)
158°F (70 °C)
S3 30%
11 ft (3,4 m) - H07 RN-F 4G1,5
80" (2,5 m) - H07 RN-F 3G1,5
2''
2''
4'' (side)
7.7'' (195 mm)/ 3.3'' (83 mm)
12'' (304 mm)
150 200 250 300
Recommended max. height
40 50 60 70 80
VALUE
1 ~ 120 V AC
60 Hz
IPX4
10
8
6
4
2
0
