HOW TO
Do regular maintenance on the LGX® PRO and LGX® PRO 2.85
INSTRUCTIONS GUIDE
This guide is designed to be a reference manual for how to do maintenance on
the LGX® PRO. Follow the instructions below or, if you prefer to watch a YouTube
video with the same instructions, use the provided link below or the YouTube
icon to the right:
https://youtu.be/1CkiVzZtmOw
01
Undo the bottom screws with a 2 mm hex key and
remove the interface plug.
04
Remove the drivegears, plastic washers and pins.
www.bondtech.se
02
Undo the top screws and remove the front plate.
05
Remove the extruder assembly from the motor.
https://youtu.be/3djZu1M0Lng
03
Rotate the extruder 90 degrees counterclockwise
and remove the middle section.
06
Remove the lever, double gear and spring from
the back SLS piece.
Page 2/8
