  • Page 1 QUICK START GUIDE LGX® lite V2...
  • Page 2 QUICK START GUIDE For the LGX® lite V2 QUICK START GUIDE Read this Quick Start Guide for proper extruder installation. Each LGX Lite V2 extruder is supplied with: • 1x LGX Lite V2 feeder; • 1x Nema14 Round 20mm pancake stepper motor (mounted on extruder) ▪...
  • Page 3 For the LGX® lite V2 LEVER POSITIONS The different lever positions of the LGX lite V2 allows for flexibility when using different kinds of filaments and for loading and unloading. Below we have outlined the intended use of these different positions.

  • Page 4: Mounting Holes

    QUICK START GUIDE For the LGX® lite V2 MOUNTING HOLES For the LGX lite V2 offers eight different mounting hole locations for different uses. Side holes may be used for peripherals such as accelerometers or toolhead boards while the top hole is ideal for mounting a filament sensor.

  • Page 5: Machine Configuration

    For the LGX® lite V2 MACHINE CONFIGURATION KLIPPER CONFIGURATION For the LGX lite V2 to work on printers where current is set Below we have listed the common Klipper parameters for with trimpots you need to adjust a couple of settings LGX lite V2 regarding the extruder system.

  • Page 6: How To Get Help

    We are available to help you with any questions or issues you may have. Simply go to our website where you can access our customer support and send us your questions or follow the provided link: https://www.bondtech.se/contact/#tab_technical-support-requests Page 6/7 www.bondtech.se...
