- Page 1 HOW TO Install LGX® ACE on the Elegoo Neptune 3 Pro Difficulty Medium Steps Time Required 20 to 30 min PRODUCT PAGE Sections...
-
Page 2: Instructions Guide
Turn the hotend heating off and wait for it to cool Power off and unplug the printer. down. Release the ribbon cable. Unscrew the two M3 BHCS holding the cowling Unscrew the three M3 BHCS holding the cowling using a 2 mm hex key. from the back. Page 2/9 www.bondtech.se... - Page 3 Unscrew the M3 BHCS holding the toolhead board Disconnect the hotend heatsink cooling fan. Take your LGX ACE and unscrew the two screws using a 2 mm hex key. holding the hotend to the extruder from the front using a 2 mm hex key.
- Page 4 Philips head screwdriver. Add two of the included hex studs and tighten Carefully snug them up using an adjustable Add two M3x6 Low Profile screws to the LGX ACE them down. spanner. Neptune 3 Pro Mount.
- Page 5 Add two M3x6 Low Profile screw to the fan shroud Add the 5015 fan to the fan shroud. Add an M3x20 SHCS to the 5015 fan. mount and fasten it to the LGX using a 2 mm hex key. Page 5/9 www.bondtech.se...
- Page 6 Insert the toolhead ribbon cable and press it down From the bottom of the printer, undo the six using the same three M3 BHCS screws and a 2 mm to lock it in place. screws using a Philips head screwdriver. hex key. Page 6/9 www.bondtech.se...
- Page 7 Loosen the bed probe with a 2 mm hex key to Remember to redo your Z offset. Check the Quick Start Guide for printer drop it down and then tighten it back up again. configuration and slicer profiles. Page 7/9 www.bondtech.se...
-
Page 8: How To Get Help
We are available to help you with any questions or issues you may have. Simply go to our website where you can access our customer support and send us your questions or follow the provided link: https://www.bondtech.se/contact/#tab_technical-support-requests Page 7/8 www.bondtech.se...
