Item
USB-C in
Button
USB-C Jack
Indicator light of Transmitter
TX
Static Red
Flashing Red
Flashing Blue
Static blue
Purple
ASK nano 4K (USB-C)
Illumination
Connect with the USB-C port of the source devices (*Note: USB- C interface
of the video source must support the DP protocol (DisplayPort))
Click to discontinue projection or resume projection
● Connected to 5V/1A adapter for power supply
● Reverse power supply supported to provide power to the signal source
when the power adapter of the signal source is connected
Illumination
TX system is booting on
TX is searching for RX
Waiting for the connection
Connected and start to presenting
No signal resource
