SUMAKE
3/8" Square Drive Non-Shut Off
Specification:
Free Speed
Square
Bolt Capacity
Torque
Air Consumption
Overall Length
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Oil Pulse Tool Pistol Type
5,500 r/min
3/8" (9.5 mm)
5/16-3/8" (M8-M10)
20.7-35.4 ft-lb (28-48 Nm)
0.45 m³/min (15.9 ft³/min)
6.8" (172.6 mm)
0.4" (12 mm)
90 psi (6.3 bar)
2.82 lbs (1.28 kg)
PNEUMATIC TOOLS
PN-5348P
Noise and Vibration:
Vibration
EN ISO 28927-2
Load:
1.4 m/s²
Uncertainty
K= 1.5 m/s
Noise
ISO 15744
Sound Pressure Level
load: 80 dB(A)
Sound power level
load: 91 dB(A)
Uncertainty
²
K= 3dB
PN-5348P-S-1404A-CPF
Remark
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sumake PN-5348P
Summary of Contents for Sumake PN-5348P
- Page 1 Air Hose (I.D.) 0.4” (12 mm) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 2.82 lbs (1.28 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 PN-5348P-S-1404A-CPF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 3/8" SQUARE DRIVE NON-SHUT OFF OIL PULSE TOOL PISTOL TYPE Model/ Serial No.： PN-5348P to which this declaration applies, complies with these normative documents: ...
- Page 3 OIL-IMPULSE TOOLS INSTRUCTION MANUAL Warm Up Warning! It might be dangerous to operate the tool, if the instructions supplied are not followed. In case of low temperature, oil action may not be generated in the first use due to viscosity of hydraulic fluid. Warm up the pulse unit approximately ten (10) seconds by fixing Anvil on the vise before starting fastening Before using, installing, repairing or changing accessories, read and understand these instructions.
- Page 4 PN-5348P 3/8" SQUARE DRIVE NON-SHUT OFF OIL PULSE TOOL PISTOL TYPE PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty PN5348P-01 O-Ring PN5348P-31 Rear Casing Packing PN5348P-02 Bearing PN5348P-32 PN5348P-03 Rotor PN5348P-33 Screw Plug PN5348P-04 Rotor Blade PN5348P-34 Bushing...
