11
Upper Chimney Bracket Installation
1. Set the position of the two chimney bracket holes.
2. Drill the two holes into the wall using an 8mm drill-bit.
3. Gently insert two wall plugs.
4. Attach the upper chimney bracket to the wall plugs
using the two ST4 × 30mm screws.
5. Assemble the chimney onto the unit and fix it in place
using two ST4 × 8mm screws as shown below.
Wall Plugs
User Manual
Upper Chimney Bracket
Need Help? You can speak to our
Support Team by calling 1300 11 4357,
or simply reach out by emailing us at
support@residentiagroup.com.au
Screws
