BAPI -Stat Quantum Installation & Operations page 4

49875_Wireless_BLE_Quantum_Temp_Hum
Specifications
Battery Power:
Two included 3.6V 14505, 14500 or equiv. lithium batteries
(Note: Standard AA batteries are not compatible)
Wire Power: 9 to 30 VDC or 24 VAC, halfwave rectified
Sensor Accuracy:
Temperature: ±1.7°F (0.95°C) from 32 to 158°F (0 to 70°C)
Humidity: ±2%RH @ 77°F (25°C), 20 to 80%RH
Temperature Range: -4 to 221°F (-20 to 105°C)
Transmission Distance: Varies by application*
Environmental Operation Range:
Temp: -4 to 149°F (-20 to 65°C)
Humidity: 10 to 90%RH non-condensing
Enclosure Material & Rating: ABS Plastic, UL94 V-0
Frequency: 2.4 GHz (Bluetooth Low Energy)
Receiver Sensitivity: -97 dBm
User Adjustable Settings:
Delta T (Temp): 0.1°F/C to 5.0°F/C
Delta T (Humidity): 0.1%RH to 5.0%RH
Transmit Interval: 30 sec to 12 hour
Sample Interval: 10 sec to 5 min
Temp Offset: ±0.1°F/C to ±5.0°F/C
Humidity Offset: ±0.1%RH to ±3.0%RH
Onboard Memory:
Sensor retains up to 16,000 readings should the
communication become interrupted. If using a Gateway,
the data is re-transmitted once communication is
re-established.
Agency: RoHS / FCC: T4FSM220913
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesirable operation.
Any changes or modifications not expressly approved by [company] could void the user's authority to operate the
equipment.
This device complies with Industry Canada (IC) license-exempt RSS standard(s). Operation is subject to the following
two conditions.
This device may not cause interference.
This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes.
L'appareil ne doit pas produire de brouillage.
L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillard est susceptible d'en compromettre le
fonctionnement.
*In-building range is dependent on obstructions such as furniture and walls
and the density of those materials. In wide open spaces, the distance may
be greater; in dense spaces, the distance may be less.
**Actual battery life is dependent on the sensor's adjustable settings and
environmental conditions.
Building Automation Products, Inc., 750 North Royal Avenue, Gays Mills, WI 54631 USA
Tel:+1-608-735-4800 • Fax+1-608-735-4804 • E-mail:sales@bapihvac.com • Web:www.bapihvac.com
BAPI-Stat "Quantum" Wireless Room Temperature
/ IC: 9067A-SM220913
Specifications subject to change without notice.
or Temperature/Humidity Sensor
Standard
Mounting
Base
60mm Mounting
Base
(Fits European
wall boxes and
junction boxes
with 60mm
mounting
centers)
Transmit Interval
Installation & Operations
BAPI-Stat "Quantum" Units Calculated Battery Life**
Sample Rate Estimated Life (years)
30 sec 30 sec
1 min 1 min
3 min 1 min
5 min 5 min
10 min 5 min
rev. 12/08/23
1.12
1.89
3.83
7.08
8.93
4 of 4
