- Page 1 Operation and Maintenance Skydoor2 Manual 406-OM-UK-501 v1.2 – 18 Dec 2023 www.glazingvision.co.uk +44 (0)1379 658300 info@glazingvision.co.uk...
-
Page 2: Table Of Contents
406-OM-UK-501 v1.2 –18 Dec 2023 Contents Section Description Page Introduction Safety Information Controls and Operation Product Safety Recovery of Skydoor2 Troubleshooting Glass Specification and Breakage Instructions Routine Testing and Maintenance Disposal at End of Life Serial Number Warranty Information Maintenance Log Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk... -
Page 3: Introduction
The product can be opened to nearly 90° for access, or various angles for ventilation as required. Glazing Vision highly recommends that for safety reasons, a balustrade is installed (by others) around the Skydoor2 if it is to be used for access – the lid can be used as a balustrade on one side. -
Page 4: Safety Information
Regular cleaning and maintenance must be carried out according to the guidelines described in this manual. • Glazing Vision strongly recommends that any work is carried out by suitably qualified individuals (e.g., Glazing Vision trained personnel or contractors, or an experienced electro-mechanical service engineer). - Page 5 • Do not knock or damage the proximity sensors so they become misaligned as that will prevent the product from operating. For more information or assistance please contact Glazing Vision. Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk Page 5 of 19...
-
Page 6: Controls And Operation
‘one touch’ operation). Note that the product will stop automatically when it becomes either fully open or closed. Do not leave your product open in rain or inclement weather. Glazing Vision cannot be held responsible for damage caused by failure to comply with this instruction. - Page 7 406-OM-UK-501 v1.2 –18 Dec 2023 Pairing a Remote Control Additional remote controls can be paired to or unpaired from the product. To put the product into pairing mode and prepare it for adding or removing a remote control follow these steps: Ensure that the product is fully closed.
- Page 8 The keypad option offers secure access into the product from the outside via a numerical pass code. To open or close the product, enter the four-digit numerical code (Glazing Vision supplies an initial code with the product and instructions for changing it as required).
-
Page 9: Product Safety
Product Safety The Skydoor2 has two infrared photoelectric sensors positioned along the treadplate on the opening end of the product. One sensor emits a beam which is received by the other during normal operation. If this beam is obstructed by any object, the lid will immediately stop moving to prevent damage to the framework, mechanisms or object and prevent entrapment. -
Page 10: Recovery Of Skydoor2
Battery override plug Figure 10 – Safety sensor override If the product still does not operate, the rooflight can be recovered by using the battery override box provided by Glazing Vision with your Skydoor2. Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk... - Page 11 In case of a power failure and the rooflight is stuck in open position, the rooflight can be closed using the Battery Override Box (see Fig 11) provided by Glazing Vision. Read the instructions on the box prior to using it.
- Page 12 Disconnect the connector from the socket and insert the override plug back in the socket. Once the issue is resolved, the product should be re-initialised. If the product is stuck in a closed position, contact Glazing Vision to arrange for an engineer to visit and resolve the issue. Re-Initialisation If the override has been used, the product may require re-initialising.
-
Page 13: Troubleshooting
Troubleshooting The Skydoor2 control board monitors the operation of the product. If a fault is detected, the control board will disable the unit to prevent possible damage. Fault and standard conditions are indicated by the status light on the control switch (figure 1). The following table shows the various status light displays and their meanings. -
Page 14: Glass Specification And Breakage Instructions
Various options are available at time of order. If specific data is required for the glazing, please contact your supplier for a glass data sheet covering the specification installed within your unit. Breakage Instructions Glass breakage is not covered under the product warranty. In the event of the glass being damaged please contact Glazing Vision for assistance. Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk... -
Page 15: Routine Testing And Maintenance
Maintenance must only be carried out by suitably qualified personnel*. The following maintenance requirements must be completed and logged on the sheets at the back of this manual. Glazing Vision offers a service/maintenance contract – please contact us for further details. - Page 16 Regular cleaning should be carried out, increasing the frequency if the area is subject to excess debris such as falling leaves or heavy soiling from atmospheric pollution. Due to the Skydoor2’s unique bonding method and the pitch built into the upstand, there should be no water ponding on the glass when installed correctly.
-
Page 17: Disposal At End Of Life
Serial Number Each Glazing Vision product has a unique serial number. A label giving this serial number is affixed to the exterior of each Skydoor2. This number should be recorded within the maintenance log section of this manual for future reference. If you need to contact us for any reason, Glazing Vision may ask for the product’s serial number to enable us to assist with your enquiry. -
Page 18: Maintenance Log
406-OM-UK-501 v1.2 –18 Dec 2023 Maintenance Log Project Address: …………………………………………………………………………………………………………………………………. Unit Serial Number: ……………………………………………………………………………………………………………………………... Work Completed Notes Name Date Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no... - Page 19 406-OM-UK-501 v1.2 –18 Dec 2023 Work Completed Notes Name Date Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no...
