Summary of Contents for KRESS Mission Mega RTKn 24000

  • Page 1 Owner's Manual...
  • Page 3 Original instructions Owner's Manual KR233E.1 KR236E.1...
  • Page 4: Product Safety

    Users can view the electronic instructions you understand the instructions and be at https://www.kress.com/en/. familiar with the controls and the proper use of the appliance. b) Never allow people unfamiliar with these Product safety instructions or children to use the appliance.
  • Page 5 appliance; The power should be off during all work - After striking a foreign object to inspect the on the mower’s under frame, such as machine for damage; cleaning or replacing the blades. - If the machine starts to vibrate abnormally, a) Keep all nuts, bolts and screws tight to and to check for damage before restarting.
  • Page 6 To satisfy EMC & RF exposure requirements, g) Recharge only with the charger specified a separation distance of 20 cm or more by Kress. Do not use any charger other should be maintained between the antenna than that specifically provided for use of this device and persons during device with the equipment.
  • Page 7 Symbols WARNING – robotic lawnmower Read operator's manual can be dangerous if incorrectly used. Read through the Operator’s manual carefully and understand Detachable supply unit the content before using your robotic lawnmower. Prohibit disassembling the machine WARNING - Keep a safe distance without authorization from the machine when operating.
  • Page 8: Component List

    Component list Wed.11/29 09:00PM...
  • Page 9 Ultrasonic Sensor Cutting Blade Charging Strips Charging Pile Rear Driving Wheel Contact Pins Rain Sensor Charging Base STOP Button Power Adapter Display Charging Base Fixing Nails Keypad RTK Antenna ON/OFF Key Hex Key START Key Wrench for RTK antenna 10. Front Wheel Magnetic Strip 11.
  • Page 10 Maximum slope within the work surface * Voltage measured at no load. Initial battery voltage reaches maximum of 20 volts. Nominal voltage is 18 volts. ** Under standard temperature (101kPa, 25°C) startup condition. High temperatures can trigger the throttling protection mode, which may potentially prolong the charging time. *** Under standard temperature (101kPa, 25°C) startup condition.
  • Page 11: Noise Data

    Noise data KR233E.1 KR236E.1 A weighted sound pressure = 50.6 dB (A), K = 3.0 dB(A) = 56.6 dB (A), K = 3.0 dB(A) A weighted sound power = 58.6 dB (A), K = 3.0 dB(A) L = 64.6 dB (A), K = 3.0 dB(A) Wear ear protection when sound pressure is over 80dB(A)
  • Page 12: Maintenance

    Mission . Spare blades are also available at your nearest Kress retailer. A. Replace the blades Usually your Mission 's blades need to be...
  • Page 13 screwdriver and remove the blades. 6. Firmly screw on the new blades and new screws for fixing blades. 7. Refit and firmly screw on the disks on the underside of Mission 8. Refit the battery and the battery cover. Important: After screwing the blade to the blade disc, make sure the blade is able to spin freely. Keep it Clean WARNING: Before cleaning, turn your Mission OFF.
  • Page 14 Battery Life The heart of the Mission is its 20V Li-Ion Battery. For proper storage of the battery, make sure it is fully charged and kept in a cool dry place between (-20 C~+60 NOTE: The recommended Mission operation temperature is between 0-55 The life-span of the Mission ’s battery depends on various factors, such as: •...
  • Page 15 Replacing the battery WARNING: Power off before attempting any adjustment, replacement or repair. Before replacing the blades, turn your Mission OFF and put on protective gloves. If you need to replace the battery, follow these steps: 1. Gently turn your Mission upside down.
  • Page 16: Troubleshooting

    Troubleshooting If your Mission does not work correctly, follow the trouble shooting guide below. If the fault persists, contact your dealer. Symptom Cause Solution Check the charging base is connected The LED light on the charging There is no power. properly to the charger and the charger base does not turn on.
  • Page 17: Environmental Protection

    Environmental protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. For battery tools: Details regarding safe disposal of used batteries At the end of the life of the appliance, remove the battery pack safely before disposing of the appliance. Do not throw batteries away or throw them in the normal trash can.
  • Page 20 www.kress-robotik.com...

This manual is also suitable for:

Mission mega rtkn 12000Kr236e.1Kr233e.1
