Installation - Valcom VP-6124 User Manual

Output
Rated Power:
Voltage:
Current:
Fusing: 3 - 2 Amps, auto-reset polyswitch fuses
Ripple and Noise:
Environmental
Operating Temperature:
Storage Temperature:
Cooling:
Humidity:
Shock:
Precautionary Notes:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
FCC
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio frequency
energy and if not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
144 Watts
24 Volts
6 Amps (3 - 2 Amp outputs)
1% P-P maximum
0 to +40
o
-40 to +85
Free Air Convection
10 to 90% (non-condensing)
10G
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
o
C

INSTALLATION

o
C
Mounting
The VP-6124 and VP-6124-E are designed for wall
mounting only. The unit should be mounted within
seven feet of an AC receptacle.
Screw mounting plate to wall and position power
supply on mounting plate via the mounting slots.
See page 4 for mounting instructions.
Connections
Connections to Valcom page control units are
shown in Figure 1.
When using the VP-6124 or VP-6124-E with
Valcom page equipment, a strap may be added
from the local ground terminal to either of the
"+" outputs.
When installing Valcom one-way amplified
horns, connect the white and black wires of the
horn to the power supply "-" and "+" terminals
respectively.
When installing Valcom one-way speakers,
connect the "-24VDC" and "GND" terminals of
the speaker to the "-" and "+" terminals
respectively.
Plug power supply into wall outlet.
Power supply activates after a 3 seconds delay.
Use CAT-5 wire.
NOTE: Each 24VDC screw terminal is fused by a
2 Amp polyswitch automatic type fuse. Therefore,
when connecting equipment to this power supply,
the load should be distributed between the (3) 2
Amp output terminals and each load should not
exceed 2 Amps.
2
