Valcom VP-324 Instruction Manual

INTRODUCTION

These instructions provide identification, installation,
connection and operation information for the VP-324,
24 Volt DC Power Supply.
IDENTIFICATION
System Design
The VP-324 is a non-regulated "unfiltered Signal
Battery" which provides 24VDC, 0.25 Amp power
supply. The output is floating with respect to ground.
Short circuit protection is provided.
Applications
•
Valcom one-way amplified speaker assemblies
•
Any application where 24VDC unfiltered signal
battery is required
Features
•
Non-regulated 24VDC "B" battery
•
Thermal overload protection
•
Floating output
•
Short circuit protected
•
Provides six Valcom power units
Capacity
•
Current 0.25 Amp at 25° C
Dimensions/Weight
•
3.00" H x 2.50" W x 2.00" D
(7.62cm H x 6.35cm W x 5.08cm D)
•
0.8 lbs. (.36 kg)
Specifications
•
Output: 24VDC +/- 3V "B" battery
Power Requirements
•
Input 105-120VAC, 60Hz, 18 Watts
VP-324
24 VOLT DC POWER SUPPLY
Environment
•
Temperature:
•
Humidity:

INSTALLATION

The VP-324 is a receptacle mount power supply
designed to be used with a third wire grounded
receptacle. A cold water pipe or earth ground should
be connected to the local ground screw terminal using
14AWG ground wire. If a two wire adapter is used,
make sure the ground tab is bonded to the local
electrical ground.
When the VP-324 is being used with Valcom page
control equipment, connect a strap between the local
ground and the "+" terminal of the power supply.
When installing Valcom one-way amplified horns,
connect the white and black wires of the horn to the
power supply "-" and "+" terminals respectively.
When installing Valcom one-way amplified speakers,
connect the -24V and ground terminals of the speaker
to the power supply "-" and "+" respectively.
1
VSP-VP-324
Issue 7
0 to +50° C
0 to 85% non-precipitating
