- Page 1 ORIGINAL MADE IN ITALY ISTRUZIONI PER L’USO DELLA TAGLIERINA ELETTRICA OPERATING INSTRUCTIONS TILE CUTTING MACHINE MODE D’EMPLOI MACHINE À DÉCOUPER LES CARREAUX BEDIENUNGSANLEITUNG FLIESENSCHNEIDMASCHINE MANUAL DE INSTRUCCIONES MÀQUINA PARA CORTAR BALDOSAS NÁVOD NA POUŽITÍ OBKLADAČSKÁ PILA...
- Page 2 Battipav srl DATI TECNICI - TECHNICAL DATA - DONNÉES TECHNIQUES - TECHNISCHE DATEN - DATOS TÉCNICOS ART. 200 / 1,8 hP/ 3950x900x 6733001 3300 mm 2330 x 2330 mm 40 mm 35 mm 145 Kg 25,4 mm 1,4kW 1260 mm OFFICIAL CHANNEL www.youtube.com/battipav...
- Page 3 230V ~ 50Hz °C 20 µF 400 VL 50 W 1400 W 2800 n 2800 n idm1...
- Page 4 5V D.C. LASER 230V 50/60Hz. (SP90138P) CLASS 3A 115V 50/60Hz. (SP90138P/A) 635 nm < 5 mW (M4x20) SP90138P (230V-50/60Hz) 02 -SP90137 RED (+) SP90138P/A (115V-50/60Hz) BLACK (-) (M4x20) (M3x8) 90169 (230V-50/60Hz) 90169/A (115V-50/60Hz) sp_v2...
- Page 5 Battipav srl...
- Page 6 Battipav srl...
- Page 7 Battipav srl...
- Page 8 Battipav srl 1.5m...
- Page 9 Battipav srl...
-
Page 10: Purpose Of This Manual
SUPPLIED THEM. THE USE OF POOR QUALITY This manual is an integral part of the machine. DISCS CAN HARM THE OPERATOR AND DAMAGE It was produced by BATTIPAV S.R.L. to provide THE MACHINE, AS WELL AS SIGNIFICANTLY those authorised to work with the machine with the SLOWING THE WORK. - Page 11 Battipav srl Store your tools in a save place Stay alert • When not in use, tools should be stored in dry and • Watch what you are doing. Use common sense. save places, out of the reach of children.
- Page 12 µF YEAR Ø max Ø int. Do not use discs for wood or metal Made by: BATTIPAV SRL Via Cavatorta, 6/1 Z.i. 2 - 48033 - Cotignola (RA) ITALY Do not wash with water under pressure 90254 Machine model IP Level...
-
Page 13: Machine Description
Battipav srl RECOMMENDED USE: CUTTING TOOL DIAMOND BLADE WET CUTTING CONTINUOUS CROWN: ceramic, single-fired ceramic, cotto and marble THE TOOL / MATERIAL TO BE CUT MATCHES ARE PURELY INDICATIVE. ALWAYS FOLLOW INTENDED INDICATIONS PROVIDED BY THE CUTTING TOOL MANUFACTURER BEFORE ANY APPLICATION. - Page 14 Battipav srl • The inclination adjustment knobs are properly CHECKING BEFORE USE tightened. THE EXTRA SAW HAS BEEN DESIGNED FOR TO MOVE THE MACHINE WORKING EXCLUSIVELY WITH WATER. Use a 4 (four)-arm tie rod, making use of the Before any cutting operation, make sure that the hooks in the transport handles.
- Page 15 Battipav srl BLADE ASSEMBLY / DISASSEMBLY CUTTING ON THE TABLE Before performing any operation or adjustment, CAUTION disconnect the machine from the supply mains. Loosen both nuts located on the blade cover guard BEFORE PERFORMING THE CUTTING OPERATIONS, and remove it.
-
Page 16: Residual Risks
RESIDUAL RISKS DO NOT MODIFY THE MARKER POSITION BY TURNING THE BEAM TOWARDS THE OPERATOR’S During the design phase, BATTIPAV SRL paid EYES. particular CAUTION to the aspects that may generate DO NOT GAZE AT THE BEAM WITH THE NAKED EYE risks for the safety and health of operators. -
Page 17: Maintenance
Battipav srl CLEANING CAUTION CAUTION • Danger of presence of electric current. The machine has an internal electric system: DO NOT WASH THE MACHINE WITH HIGH CONNECT THE MACHINE TO A SYSTEM WITH PRESSURE WATER JETS DIFFERENTIAL PROTECTION AND EFFECTIVE EARTH WIRE. - Page 18 Battipav srl DISPOSAL When parts wear out or when the machine is finally scrapped, waste disposal must be carried out in compliance with the laws in force. Electric Motor Aluminium Steel Copper Polyamide Main Body Steel Polyamide Submersed pump Polyamide...
-
Page 19: Troubleshooting
Battipav srl TROUBLESHOOTING HAVE YOUR TOOL REPAIRED BY A QUALIFIED PERSON This electric tool complies with the relevant safety rules. Repairs should only be carried out by qualified persons using original spare parts, otherwise this may result in considerable danger to the user.
