iDataLink maestro Rr Install Manual

For 2011-2014 mazda 2
Hide thumbs Also See for maestro Rr:

Advertisement

Table of Contents

SELECT VEHICLE
PRINT PAGES NEEDED
HOW TO USE THIS INSTALL GUIDE
1
Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro RR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certifi ed technician. Logos and trademarks used here in
are the properties of their respective owners.
WARNING
all of the guides in this compilation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the maestro Rr and is the answer not in the manual?

Questions and answers

Related Manuals for iDataLink maestro Rr

Summary of Contents for iDataLink maestro Rr

  • Page 1 Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.

  • Page 2: Install Guide

    PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.

  • Page 3: Need Help

    Mazda 2 2011-2014 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.

  • Page 4: Installation Instructions

    STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.

  • Page 5: Wiring Diagram

    STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...

  • Page 6: Radio Wire Reference Chart

    Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...

  • Page 7: Module Diagnostics

    Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...

  • Page 8: Troubleshooting Table

    4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 9 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 10 Mazda 3 2004-2013 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 11 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 12 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 13 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 14 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 15 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 16 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 17 Mazda 3 without touchscreen 2014-2018 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 18 STEP 7 If the vehicle DOES have a factory amplifi er: • Unlug the HRR-MA1 4-pin white and 4-pin black • Connect all the harnesses to the Maestro RR module then connectors. test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs.
  • Page 19 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GRAY...
  • Page 20 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 21 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 22 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 23 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 24 Mazda 5 2006-2011 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 25 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 26 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 27 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 28 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 29 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 30 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 31 Mazda 5 2012-2017 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 32 STEP 7 If the vehicle DOES have a factory amplifi er: • Unlug the HRR-MA1 4-pin white and 4-pin black • Connect all the harnesses to the Maestro RR module then connectors. test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs.
  • Page 33 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / ABOVE GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GRAY STEP 5...
  • Page 34 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 35 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 36 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 37 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 38 Mazda 5 without touchscreen 2016-2017 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 39 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 40 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 41 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 42 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 43 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 44 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 45 Mazda 6 2003-2013 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 46 • Unlug the HRR-MA1 4-pin white and 4-pin black STEP 7 connectors. • Connect the HRR-MA1 4-pin white to 4-pin white connector • Connect all the harnesses to the Maestro RR module then with RCAs. Connect the 4-pin black to 4-pin black test your installation. connector with RCAs.
  • Page 47 FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX *VEHICLES WITH BLUETOOTH MAESTRO RR MODULE BUTTONS ON STEERING WHEEL ONLY N.C. AA Y W U S Q G E C A GREEN AB Z...
  • Page 48 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 49 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 50 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 51 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 52 Mazda 6 2014-2015 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 53 • Determine if the vehicle has a factory amplifi er. Look for badges on the radio, door panels and dash that indicate the • Connect all the harnesses to the Maestro RR module then presence of an amplifi er (ex: BOSE).
  • Page 54 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS BLUE N.C. STEP 6 WHITE GREEN FACTORY RADIO HARNESS MAESTRO RR MODULE STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE DATA CABLE Automotive Data Solutions Inc.
  • Page 55 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 56 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 57 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 58 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 59 Mazda 6 without touchscreen 2016-2017 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 60 STEP 7 If the vehicle DOES have a factory amplifi er: • Unlug the HRR-MA1 4-pin white and 4-pin black • Connect all the harnesses to the Maestro RR module then connectors. test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs.
  • Page 61 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GREEN/ORANGE...
  • Page 62 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 63 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 64 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 65 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 66 Mazda CX-3 without touChsCreen 2016-2020 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 67 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 68 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 69 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 70 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 71 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 72 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 73 Mazda CX-5 2012-2015 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 74 • Determine if the vehicle has a factory amplifi er. Look for badges on the radio, door panels and dash that indicate the • Connect all the harnesses to the Maestro RR module then presence of an amplifi er (ex: BOSE).
  • Page 75 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS BLUE N.C. STEP 6 WHITE GREEN FACTORY RADIO HARNESS MAESTRO RR MODULE STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE DATA CABLE Automotive Data Solutions Inc.
  • Page 76 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 77 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 78 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 79 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 80 Mazda CX-5 without touChsCreen 2017-2020 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 81 Note: only connect purple/white wire to radio reverse input or module damage will occur. STEP 6 • Connect all the harnesses to the Maestro RR module then • Connect the blue POWER ANT terminal to amplifi ed test your installation.
  • Page 82 VEHICLE STEP 3 FACTORY RADIO HARNESS WHITE N.C. BLUE N.C. STEP 6 STEP 4 MAESTRO RR MODULE BLUETOOTH MODULE BEHIND/RIGHT OF GLOVE BOX N.C. AA Y W U S Q G E C A GREEN AB Z X V T R...
  • Page 83 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 84 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 85 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 86 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 87 Mazda CX-7 2007-2008 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 88 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 89 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 90 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 91 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 92 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 93 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 94 Mazda CX-7 2009 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 95 STEP 7 If the vehicle DOES have a factory amplifi er: • Unlug the HRR-MA1 4-pin white and 4-pin black • Connect all the harnesses to the Maestro RR module then connectors. test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs.
  • Page 96 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GRAY/ORANGE...
  • Page 97 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 98 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 99 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 100 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 101 Mazda CX-7 2010-2012 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 102 STEP 7 If the vehicle DOES have a factory amplifi er: • Unlug the HRR-MA1 4-pin white and 4-pin black • Connect all the harnesses to the Maestro RR module then connectors. test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs.
  • Page 103 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R BROWN...
  • Page 104 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 105 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 106 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 107 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 108 Mazda CX-9 2007-2008 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 109 STEP 7 If the vehicle DOES have a factory amplifi er: • Unlug the HRR-MA1 4-pin white and 4-pin black • Connect all the harnesses to the Maestro RR module then connectors. test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs.
  • Page 110 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / ABOVE GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R LTGREEN/RED STEP 5...
  • Page 111 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 112 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 113 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 114 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 115 Mazda CX-9 2009-2012 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 116 STEP 7 If the vehicle DOES have a factory amplifi er: • Unlug the HRR-MA1 4-pin white and 4-pin black • Connect all the harnesses to the Maestro RR module then connectors. test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs.
  • Page 117 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / ABOVE GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R LTGREEN/RED STEP 5...
  • Page 118 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 119 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 120 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 121 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 122 Mazda CX-9 2013-2015 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 123 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 124 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 125 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 126 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 127 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 128 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 129 Mazda MX-5 2006-2015 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 130 • Determine if the vehicle has a factory amplifi er. Look for badges on the radio, door panels and dash that indicate the • Connect all the harnesses to the Maestro RR module then presence of an amplifi er (ex: BOSE).
  • Page 131 VEHICLE STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 132 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 133 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 134 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 135 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 136 Mazda MX-5 without touchscreen 2016-2018 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 137 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 138 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 139 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 140 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 141 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
  • Page 142 PRODUCTS REQUIRED PROGRAMMED FIRMWARE: MA1-RR-AS iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-MA1 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in are the properties of their respective owners.
  • Page 143 Mazda RX-8 without touchscReen 2009-2011 WELCOME ADDITIONAL INFORMATION AND ACCESSORIES Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are HEAD UNIT ADAPTER: now a few simple steps away from ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 enjoying your new car radio with enhanced features.
  • Page 144 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 145 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 146 Wire Description Refer to camera/ Green/Red E-Brake LtGreen LtGreen radio manual Refer to camera/ Reverse Light* Purple/White Purple/White Green/White radio manual Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Steering Wheel Controls (DATA) Blue/Yellow Blue/Yellow Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 147 Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE. • 1 GREEN flash After radio boots up : Normal operation. • 3 GREEN flashes Bluetooth is activated. Turns off after one minute: Normal operation. • • Normal operation (inactive). Automotive Data Solutions Inc. © 2023 MA1-RR-AS-(HRR-MA1)-EN maestro.idatalink.com...
  • Page 148 4-pin connectors on the MA1 harness. Plug them into the radio’s RCA preouts. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).

This manual is also suitable for:

Mastro rr

Table of Contents
