Technical Assistance - Valcom V1011MR Specifications

•
The backbox rails sit on top of the "T" bar of the ceiling
bridge (see Figure 3). The mounting ring rails lay on the
tile to give it support (see Figure 4). The height of these
bars can be adjusted by loosening the wing nuts. Attach
rails to the backbox by placing rails through the slot
provided on the backbox and securing to the backbox
with a wing nut.
Valcom Page
Adapter
70 Volt Amp
Page
Out
Valcom -24VDC
Power Supply
FIGURE 1 - TYPICAL CONNECTIONS TO VALCOM PAGE ADAPTER
FIGURE 2 - CONNECTIONS TO 25 OR 70 VOLT PAGING SYSTEM

TECHNICAL ASSISTANCE

When trouble is reported, verify there are no broken
connections. Assistance in troubleshooting is available from
the factory. Call (540) 563-2000 and press 1 for Technical
Support, or visit our website at http://www.valcom.com.
Valcom equipment is not field repairable. Valcom, Inc.
maintains service facilities in Roanoke, VA. Should repairs be
necessary, attach a tag to the unit clearly stating company
name, address, phone number, contact person, and the
nature of the problem. Send the unit to:
One-Way
Amplified
Speaker
T
R
-24VDC
GND
70 Volt Speakers
V-1095
-24VDC
Valcom
Power
Supply
3
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
Ring Tip GND -24V
Amplifier Detail
Screw Designations
Twisted pair telephone
wire
T
R
-24VDC
GND
One-Way
Amplified
Speakers
(up to 150)
947019
