Unytouch U14-OC121-B Specifications

Y
UN TOUCH
R
MANUFACTURING
TOUCH PART NUMBERS
U14-OC121UR-B Resistive USB Touch
U14-OC121SR-B Resistive Serial Tocuh
ACCESSORIES
U14-ABSE Adjustable Base
U09-APMB Adjustable Black Polemount
U09-AWMB-8 8 Kg Wall Mount Bracket
Visit us:
www.unytouch.ca
sales@unytouch.ca
12.1" Panel Mount LCD
WARRANTY
Speakers
Included!
Vesa Mount
Base OPTIONAL
REAR VIEW
APPLICATIONS:
- Industrial
- Gaming
- Custom or OEM Applications
- Retail

MAIN SPECIFICATIONS

PANEL
Cell Type
Pixel Arrangement
Glass Surface
3 YEAR
Pixel Number
Pixel Pitch
Display Size
Active Area
Color Depth
Light Source
Brightness
Contrast Ratio
Viewing Angle
INPUT SIGNAL
Video
Sync
Frequency
RESOLUTION
Supported
Recommended
CONTROL
Front Panel Winsticker (OSD)
POWER
SIDE VIEW
Input Voltage
Power Rating
OPERATING CONDITION
Temperature
Humidity
STORAGE CONDITION
Temperature
Humidity
OTHER
Audio
Dimensions (W x H x D)
Weight (Net/Gross)
Options
Certification
"artistry in technology"
U14-OC121-B
Color active matrix TFT (Thin-Film-Transistor) LCD Panel
RGB vertical stripe
Anti-Glare coating
800(H) x 600(V)
0.3075(H) mm x 0.3075(V) mm
12.1" viewable diagonal area
264.0(H) x 184.5(V) mm
262K Colors
Long life, 50,000 hours (typ)
370 cd/m 2
450:1
Horizontal (typ) (L ~ R: -70° ~ +70° ), Vertical (typ) (U ~ D: -50° ~ +60° )
Analog RGB (0.7/1.0 Vp-p, 75 ohms)
Composite Sync
Fh: 30 - 82 Khz, Fv: 60 - 75Khz
1024 x 768 @ 60/70/75 Hz
800 x 600 @ 60/70/75 Hz
640 x 480 @ 60/70/75 Hz
720 x 400 @ 60/70 Hz
640 x 350 @ 70 Hz
800 x 600 @ 60 Hz
800 x 600 @ 60 Hz
Power, Menu Select, + (Inc), - (Dec), Auto Adjust, Brightness, Contrast, H-
Position, V-Position, Phase, Color, Default, Volume, Language, Memory Recall
AC: 90 to 260 VAC, 50/60 Hz DC: 12V/1.2A
Operation: 30 Watt, Off: < 5 Watt
-10°C ~ 65°C
10% ~ 90% (no condensation)
-30°C ~ 70°C
10% ~ 90% (no condensation)
2W x 1 Speaker
264 x 225 x 40.5 mm
3 Kg/4Kg
Video-In: 1 x RCA Connector, 1 x S-Video
FCC, CE
Unytouch Manufacturing, Inc.
Brampton, Ontario, L6T 5M4
Toll Free: (800) 260 6249
27 Armthorpe Road
Phone: (905) 792-0542
Fax: (905) 792-2843
