Unytouch U09-O150-B Specifications

Y
UN TOUCH
R
MANUFACTURING
TOUCH PART NUMBERS
Resistive 5 Wire Dual
U09-O150DR-B
Touch Ser/USB
Capacitive Serial Touch U09-O150SC-B
Capacitive USB Touch U09-O150UC-B
IR USB Touch U09-O150UI-B
SAW USB Touch U09-O150US-B
Visit us:
www.unytouch.ca
sales@unytouch.ca
15" Black Open Frame/Panel Mount
WARRANTY
Speakers
Included!

Vesa Mount

Adjustable Mounting
Brackets
REAR VIEW
APPLICATIONS:
- Industrial
- Gaming
- Custom or OEM Applications

MAIN SPECIFICATIONS

LCD Panel
Resolution
Contrast Ratio
Brightness
3 YEAR
Response Time
Pixel Pitch
Plug & Play
OSD (On Screen Display)
Touch Technology
Touch Interface
Touch Active Area (W/H)
Operating Environment
Storage Conditions
Product Dimensions (W/H/D) mm
Package Dimensions (W/H/D) mm
Weight Gross
Monitor Tilting Degree
Color
Viewing Angle
MTBF
PC Video Interface
SIDE VIEW
Horizontal Scan Rate (Khz)
Vertical Scan Rate (Hz)
Display Mode
Front Control
Electrical Power
Power Consumption
Certification
"artistry in technology"
U09-O150-B
15" TFT Active Matrix LCD Display
1024 x 768 Pixels, 16.7M Colors
500:1
250 cd/m 2
12 ms
0.297 mm x 0.297 mm
DDC 2B Compliance
Auto Tune, Brightness, Contrast, Clock, Phase, H-position, V-position,
Recall
5 Wire Resistive, Capacitive Technology, IR, SAW
USB, Serial, Combo
13.39"(340.00 mm) x 10.72" (272.4 mm)
0°C-40 °C (32 °F-104 °F) 10%-80% (no condensation)
-20 °C-60 °C (-4 °F-140 °F) 10%-90% (no condensation)
14.37"(365mm) x 11.41"(290mm) x 2.12"(54mm)
18.6"(472mm) x 17.5"(444mm) x 8.2"(208mm)
11.5 Lbs (5.21 Kgs)
Fixed
Black
-75°/+75°/-60°/+60°(L/R/U/D)
50,000 Hours
Analog RGB (VGA)
30-60 Khz
56-75 Hz
VGA 720 x 400 (70 Hz)
VGA 640 x 480 (60/66/70/72/75 Hz)
SVGA 800 x 600 (60/70/7275 Hz)
XGA 1024 x 768 (56/7075 Hz)
Power On/Off with LED, Menu Auto Tune, Adjustment (+/-)
Adapter Input 100-240 VAC, 50-60 Hz 1.5A
Adapter Output 12VDC, 3.33A (C+)
40W (Max)
FCC, CE, UL, TC099, CB, SASO, FDA
Unytouch Manufacturing, Inc.
27 Armthorpe Road
Brampton, Ontario, L6T 5M4
Phone: (905) 792-0542
Toll Free: (800) 260 6249
Fax: (905) 792-2843
