Unytouch U09-T190 Specifications

,,
19 LCD STINGRAY SERIES
U09-T190
Models
Part Number
Description
Type
U09-T190SR-SB 19" LCD
5 Wire Resistive
U09-T190SU-SB
19" LCD
5 Wire Resistive
Interface
Color
Serial
Black
USB
Black

Monitor Specifications

U09-T190
Feature Specification
LCD Panel 19" SXGA TFT LCD Active Martix Display
1280 x 1024 Pixel, 16.7M Colors
Resolution
Contrast Ratio 600:1
300 cd/m2
Brightness
Response Time 8 ms
0.294 mm x 0.294 mm
Pixel Pitch
Plug & Play DDC 2B Compliance
Auto-tune, Brightness, Contrast, Clock,
OSD (On Screen Display)
Phase, H-position, V-position, Recall
5 Wire Resistive, Capacitive Technology
Touch Technology
Touch Interface USB or Serial
14.90"(378.50 mm) x 11.93"(303.00 mm)
Touch Active Area
Operating Environment 0˚C-50˚C (32˚F-104˚F)10%-80% (no condensation)
-20˚C-60˚C (-4˚F-140˚F)10%-90% (no condensation)
Storage Conditions
Product Dimension (W/H/D) mm 19.37"(492mm) x 17.44"(443mm) x 7.3"(185mm)
18.6"(472mm) x 17.5"(444mm) x 8.2"(208mm)
Package Dimension (W/H/D) mm
Weight Net / Gross 10 Lbs (4.54 Kg) / 13.9 Lbs (6.3 Kg)
PED-3 Cable Management Base
Stand Style
Mounting Option Desktop Placement, Bolt Down & VSA Mountable
160 Degree
Monitor Tilting Degree
Color Black
-80˚/+80˚/-80˚/+80˚(L/R/U/D)
Viewing Angle
MTBF 50,000 Hours
Analog RGB (VGA)
PC Video Interface
Horizontal scan rate (KHz) 30 ~ 60 KHz
56 ~ 75 KHz
Vertical scan rate (Hz)
VGA 720x400 (70Hz)
Display Mode
VGA 640x480 (60/66/70/72/75 Hz)
SVGA 800x600 (60/70/72/75 Hz)
XGA 1024 x 768 (56/70/75 Hz)
VGA 1280x1024 (56/70/75 Hz)
Front Control Power On/Off with LED, Menu, AutoTune, Adjustment (+/-)
Built-in Speaker N/A
Electrical Power Adapter Input 100-240 VAC,50-60HZ 1.5A
Adapter Output 12 VDC, 3.33A (C+)
40W (Max)
Power Consumption
Certification FCC, CE, UL, TC099, CB, SASO, FDA
* See Optional Accessories

Optional Accessories

U04-APMB Pole Mount
U04-AWMA Short Robotic Wall Arm
P-XM90K MSR Card Reader, Black, KBW
P-XM90U MSR Card Reader, Black, USB
US-MSR-BRA MSR Bracket Kit
2
"artistry in technology"
Specifications subject to change without notice.
