Unytouch U14-OC104-SB Specifications

Y
UN TOUCH
R
MANUFACTURING
TOUCH PART NUMBERS
U14-OC104UR-SB Resistive USB Touch
U14-OC104SR-SB Resistive Serial Touch
U14-OC104UC-SB Capacitive USB Touch
ACCESSORIES
U14-ABSE Adjustable Base
U09-APMB Adjustable Black Polemount
U09-AWMB-8 8 Kg Wall Mount Bracket
Visit us:
www.unytouch.ca
sales@unytouch.ca
10.4" Panel Mount LCD
Included!
Vesa Mount
Base OPTIONAL
REAR VIEW
APPLICATIONS:
- Industrial
- Gaming
- Custom or OEM Applications
- Retail

MAIN SPECIFICATIONS

PANEL
Cell Type
Pixel Arrangement
Glass Surface
Pixel Number
Pixel Pitch
Display Size
Active Area
Color Depth
Light Source
Brightness
Contrast Ratio
Viewing Angle
INPUT SIGNAL
Video
Speaker
Sync
Frequency
RESOLUTION
Supported
Recommended
CONTROL
Top Back (OSD)
POWER
SIDE VIEW
Input Voltage
Power Rating
OPERATING CONDITION
Temperature
Humidity
STORAGE CONDITION
Temperature
Humidity
OTHER
Audio
Dimensions (W x H x D)
Weight (Net/Gross)
Options
Certification
"artistry in technology"
U14-OC104-SB
Color active matrix TFT (Thin-Film-Transistor) LCD Panel
RGB vertical stripe
Anti-Glare coating
800(H) x 600(V)
0.264(H) mm x 0.264(V) mm
10.4" viewable diagonal area
211.2(H) x 158.4(V) mm
262K Colors
Long life, 50,000 hours (typ)
350 cd/m 2
150:1
Horizontal (typ) (L ~ R: -50° ~ +50° ), Vertical (typ) (U ~ D: -35° ~ +35° )
Analog RGB (0.7/1.0 Vp-p, 75 ohms)
Composite Sync
Fh: 30 - 82 Khz, Fv: 60 - 75Khz
1024 x 768 @ 60/70/75 Hz
800 x 600 @ 60/70/75 Hz
640 x 480 @ 60/70/75 Hz
720 x 400 @ 60/70 Hz
640 x 350 @ 70 Hz
800 x 600 @ 60 Hz
800 x 600 @ 60 Hz
Auto Adjust, Brightness, Contrast, H-Position, V-Position, Phase, Color,
Default, Volume, Language, Memory recall
AC: 90 to 260 VAC, 50/60 Hz DC: 12V/1.2A
Operation: 25 Watt, Off: < 5 Watt
-10°C ~ 65°C
10% ~ 90% (no condensation)
-30°C ~ 70°C
10% ~ 90% (no condensation)
2W x 1 Speaker
264 x 225 x 40.5 mm
3 Kg/4Kg
Video-In: 1 x RCA Connector, 1 x S-Video
FCC, CE
Unytouch Manufacturing, Inc.
27 Armthorpe Road
Brampton, Ontario, L6T 5M4
Phone: (905) 792-0542
Toll Free: (800) 260 6249
Fax: (905) 792-2843
