Unytouch U09-T150 Specifications

,,
15 LCD STINGRAY SERIES
U09-T150-SB
Models
Part Number
Description Type
U09-T150SR-SB 15" LCD 5 Wire W/Speakers
U09-T150UR-SB
15" LCD 5 Wire W/Speakers
U09-T150DR-SB
15" LCD 5 Wire W/Speakers
with speakers
Interface
Color
Serial
Black
USB
Black
Dual Serial/USB
Black
model
Monitor Specifications U09-T150-SB
Specification
Feature
LCD Panel 15" TFT LCD Active Matrix Display
1024 x 768 Pixel, 16.7M Colors
Resolution
Contrast Ratio 450:1
250 cd/m2
Brightness
Response Time 12 ms
0.297 mm x 0.297 mm
Pixel Pitch
Plug & Play DDC 2B Compliance
AutoTune, Brightness, Contrast, Clock,
OSD (On Screen Display)
Phase, H-position, V-position, Recall
5 Wire Resistive
Touch Technology
Touch Interface USB, Serial, Dual
11.95"(303.50 mm) x 8.96"(227.50 mm)
Touch Active Area
Operating Environment 0˚C-40˚C (32˚F-104˚F) 10%-80% (no condensation)
-20˚C-60˚C (-4˚F-140˚F) 10%-90% (no condensation)
Storage Conditions
Product Dimension (W/H/D) mm 13.5"(343mm) x 14.3"(363mm) x 7.3"(185mm)
18.6"(472mm) x 17.5"(444mm) x 8.2"(208mm)
Package Dimension (W/H/D) mm
Weight Gross 15.80 Lbs (7.16 Kg)
PED-3 Cable Management Base
Stand Style
Mounting Option Desktop Placement, Bolt Down & VESA Mountable
160 Degree
Monitor Tilting Degree
Color Black
Viewing Angle -75˚/+75˚/-70˚/+70˚(L/R/U/D)
MTBF 50,000 Hours
PC Video Interface Analog RGB (VGA)
Horizontal scan rate (KHz) 30 ~ 60 KHz
Vertical scan rate (Hz) 56 ~ 75 KHz
Display Mode VGA 720x400 (70Hz)
VGA 640x480 (60/66/70/72/75 Hz)
SVGA 800x600 (60/70/72/75 Hz)
XGA 1024 x 768 (56/70/75 Hz)
Front Control
Power On/Off with LED, Menu, AutoTune, Adjustment (+/-)
Built-in Speaker
Yes
Electrical Power
Adapter Input 100-240 VAC,50-60HZ 1.5A
Adapter Output 12 VDC, 3.33A (C+)
Power Consumption
30W (Max)
Certification
FCC, CE, UL, TC099, CB, SASO, FDA
* See Optional Accessories
Optional Accessories
GV-Polemount-BL Pole Mount
GV-Wall-Mount-Arm Short Robotic Wall Arm
P-XM90K MSR Card Reader, Black, KBW
P-XM90U MSR Card Reader, Black, USB
US-MSR-BRA MSR Bracket Kit
2
"artistry in technology"
Specifications subject to change without notice.
