Unitech MS210 Specifications

The MS210 CCD scanner is a reliable,
low cost bar code reader suitable for a wide range of environments.
Its features and price make it the best solution for Retail,
Medical and Light Industrial applications.
the scanning process easier and more comfortable.
Aside from good looks, it is also rugged enough to
withstand multiple six feet (1.8 M) drops to concrete.
multiple interface design supports keyboard wedge,
RS232 and wand emulation by simply replacing the cable.
This feature also prevents downtime caused by damaged cables.
In addition, the IBM PC XT/AT keyboard wedge interface
supports 8 different character sets.
The powerful built-in decoder reads and
discriminates all major symbologies,
reducing processing time and labor costs,
Affordable
Reliable & Affordable
Ergonomic
The ergonomic design makes
Flexible
The MS210-1 flexible,
while increasing accuracy.
MS210-1
The MS210 is manufactured at our ISO 9001 certified factory and
comes with a 2-year warranty.
Scanning Features
.
.
Scanning width up to 120mm
.
Resolution up to 0.1 mm (4 mils)
.
Reading distance up to 25mm
Power consumption:
Operating current 85mA 15mA (5V)
Standby current 20mA 10mA (5V)
Interfaces
.
.
Keyboard wedge (PC XT/AT, PS/2 and Macintosh ADB, DEC, and IBM terminal )
.
RS232 (May require external AC adapter)
Wand Emulation
Built-in Decoder Features:
.
.
Reads all major bar code symbologies
.
Reads reverse bar code labels
.
Trigger, Flash, Multiscan and One press one mode
.
Configuration through bar code setup
Extensive data formatting features
High
Performance
