ZEB Horizon ZEB Cam Firefly 8SE Reset

Overview

This article explains how to reset the ZEB Cam for ZEB Horizon - Firefly model 8SE.

Note: Please check your camera model first to make sure you are following the correct procedure.

Procedure

1. Remove the camera from the scan head by unscrewing the 4 retaining screws using T20 Torx screwdriver.

https://knowledge.faro.com/Hardware/GeoSlam/ZEB_Horizon_and_Horizon_RT/ZEB_Horizon_ZEB_Cam_Firefly_8SE_Reset

Updated: Wed, 11 Oct 2023 12:10:46 GMT

Need help?

Do you have a question about the Firefly 8SE and is the answer not in the manual?

Page 1 ZEB Horizon ZEB Cam Firefly 8SE Reset Overview This article explains how to reset the ZEB Cam for ZEB Horizon - Firefly model 8SE. Note: Please check your camera model first to make sure you are following the correct procedure.
Page 2 2. Remove the camera from the frame. a. Remove the lens protection cowling from the front of the camera (simply pull forwards and off). b. Remove the fixing screw in the base of the camera using a 4mm hex key. c.
Page 3 g. Disconnect the cable assembly from the camera mini USB B socket. 3. Remove the SD card from the camera. 4. Power on the camera by pressing the Power/Mode button on the front of the camera. 5. Ensure the camera is set to video mode. Short press the Power/Mode button on the front of the camera to cycle between Video mode and Camera mode.
Page 4 7. Select the Camera settings and the swipe down to the Default Setting option. 8. Select the Default Setting option and the touch the Tick box to accept this selection. The camera will reset then briefly power off and back on. 9.
Page 5: Video Settings
Video settings Video settings Changes to default Video Resolution 4K (3840x2160) 30 FPS Microphone Volume 11. On the Camera Settings sub-page make the following: Camera Settings Camera Settings Changes to Default LCD brightness LOW (to save battery life) Auto Shutdown 3 Min Screen Off Time Setup...
