Getting Started with the MR550
Introduction
The MR550 series is a stationary
terminal featuring the Windows CE® 3.0
operating system, incorporating an
integral barcode slot reader, triple track
magnetic stripe reader, proximity reader,
or finger print reader.
The MR550's PCMCIA type II slot
provides wire or wireless communication
for LAN or WAN capability.
The MR550 provides the user with a
standard Windows-based environment
for simple operation and customization.
The MR550 is well suited for time & attendance, access control, loyalty
programs, work-in-process applications, price checking ,food court
systems, and many other data collection applications.
Notes
The MR550 is equipped with a Lithium-Ion battery pack. It is possible that
the unit may not power-on due to battery discharge as a result of storage.
In the above situation, plug the MR550 to the 13.5VAC Power Supply and
charge the unit for at least 16 hours to fully charge the main battery.
The MR550 can operate normally for about 6 hours (without backlight)
and retain backup data for 7 days without external power.
MR550 and Accessories
After opening box, please make sure the following items are present:
RS232 Cable
MR550
MSR, Bar
Code Slot,
or Proximity
Reader
Speaker
Touch
Screen
Lock
Keypad
CD Manual
First Steps with the MR550
1.
Insert key into lock and turn
key with anti-clockwise
direction.
3. Ensure the UPS
Use a pen or screw driver to push the dip
battery is connected
switch to the side away from the connector
via the white connector.
(towards the bottom of the unit) to enable
the backup battery.
2.
Lift up back-plate to about 45°.
4.
Plug the 13.5VAC Power Supply
into the MR550's terminal block's
AC connector on inner side of
back-plate
Plug the Power Supply into your
wall socket.
Charge the UPS battery for at
least 16 hours.
