  • Page 1 RODIACUT 150 - 250 NO Bruksanvisning DE Bedienungsanleitung EN Instructions for use FI Käyttöohje FR Instruction d’utilisation PL Instrukcja obsługi ES Instrucciones de uso CS Návod k používání IT Istruzioni d’uso TR Kullanim kilavuzu NL Gebruiksaanwijzing HU Kezelési útmutató PT Instruções de serviço...
  • Page 2 Overview No.: FF30150 No.: FF30250 B Start up FF35120 / FF35121 FF35120 FF35120 FF35121 FF35121 FF35120 = Ø 15 x 65 mm FF35121 = Ø 20 x 85 mm RODIACUT 150 RODIACUT 250...
  • Page 3 Intro DEUTSCH - Originalbetriebsanleitung! Seite 2 Bedienungsanleitung bitte lesen und aufbewahren! Nicht wegwerfen! Bei Schäden durch Bedienungsfehler erlischt die Garantie! Technische Änderungen vorbehalten! ENGLISH Page 10 Please read and retain these directions for use. Do not throw them away! The warranty does not cover damage caused by incorrect use of the equipment! Subject to technical modifications! FRANÇAIS Page 17...

  • Page 4: Table Of Contents

    Contents Page Safety Notes ........................11 Intended use........................11 General Power Tool Safety Warnings ................11 Special Safety Instructions ....................12 Technical Data ........................13 Function of the Unit ......................13 Overview (A) ........................13 Start of operation ......................13 Fastening possibilities (B) ....................

  • Page 5: Safety Notes

    Safety Notes Intended use The RODIACUT 150 and 250 diamond core drill rig is only to be used for drilling in reinforced concrete, brickwork, asphalt and other rock types using an appropriate drill bit. The RODIACUT 150 drill rig is intended to accommodate the RODIADRILL 160 and 200 drill motor.

  • Page 6: Special Safety Instructions

    d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

  • Page 7: Technical Data

    Ventilation button Borehole for water extraction ring Feed unit As the system consists of coordinated components, please only use original ROTHENBERGER spare parts, accessories and diamond drill bits in order to enable optimum efficiency of the equipment at all times.

  • Page 8: Fastening Possibilities (B)

    Fastening possibilities a) Dowel fastening on concrete or brickwork (picture B-1)  Measure and drill a mounting hole for the dowel fastening. Diameter in mm Depth in mm Concrete (Item no. FF35120) 15 mm 65 mm Brickwork (Item no. FF35121) 20 mm 85 mm ...

  • Page 9: Handling

    Make sure the feed gear cannot be operated unintentionally. Use the locking button (1) to secure the feed unit.  RODIACUT 150: Insert the motor into the receptacle (2) of the drill rig from the top and fas- ten by means of the screw.

  • Page 10: Care And Maintenance

    You can find suitable accessories in the main catalog or at www.rothenberger.com Customer service The ROTHENBERGER service locations are available to help you (see listing in catalog or on- line) and replacement parts and service are also available through these same service locations.
  • Page 11 ROTHENBERGER Werkzeuge GmbH Industriestraße 7 D-65779 Kelkheim / Germany Telefon +49 6195 / 800 - 0 Telefax +49 6195 / 800 - 3500 info@rothenberger.com rothenberger.com Änderungen und Irrtümer vorbehalten...
