WMF coffeemachines
WMF 5000 S planning information – Easy Milk
Waste water connection
Optional:
Area for counter cut out connection
minimum 50x60 or Ø70
Water and power connection
Optional:
Area for counter cut out connection
minimum 50x60 or Ø70
Placement in hatched area is freely
selectable
http://www.wmf-kaffeemaschinen.de/fachplaner
WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)
Optional: vending unit
Card reader width 130 mm
Coin Checker and coin
changer 105 mm
or
On site
3x1,5 mm
2
, length appr. 1m
5x2,5 mm
2
, length appr. 2,5m
On site
µ
Optional feet
100 mm
Optional: pipe for
grounds disposal
70 x 120 x 250 mm
(extension with second
pipe possible)
Optional: cut-out for
grounds through counter
Optional: cut-out for under
machine cooler milk hose

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Easy Milk 5000 S and is the answer not in the manual?

Questions and answers

Related Manuals for WMF Easy Milk 5000 S

Summary of Contents for WMF Easy Milk 5000 S

  • Page 1 Placement in hatched area is freely Optional: cut-out for under selectable machine cooler milk hose On site 3x1,5 mm , length appr. 1m 5x2,5 mm , length appr. 2,5m On site http://www.wmf-kaffeemaschinen.de/fachplaner WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)
  • Page 2 For operating, service, and safety reasons the machine should be installed with a clearance Clearance from the building or non-WMF components of not less than 50 mm at the sides and 60 mm at the back. A minimum working space of 800 mm in front of the coffee machine is recommended.
  • Page 3 For connection from below through the counter a cut-out must be made in the hatched area on-site according to drawing (see top view). For drinking water with carbonate hardness above 5°dKH (carbonate hardness), a WMF water filter should be fitted upstream.
  • Page 4 For more information as the instruction manual , safety data sheets and certificates , see: http://mediacenter.wmf.com/servicecenter/ All information refers to coffee machines/ equipment as standard version. Individual solutions can differ from the standard version. http://www.wmf-kaffeemaschinen.de/fachplaner WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)
