Summary of Contents for InWin NEPTUNE DN120 PRO

  • Page 1 User Manual...
  • Page 2 Product Video Information Neptune Series Product Video Neptune DN120 PRO / DN140 PRO Installation Video...
  • Page 3 Product Story Neptune's Ultimate Pro Grade Fan The DN PRO fans are the flagship fan of the Neptune series. These silent, high-static pressure fans achieve this notoriety with their revolutionary blade design, emphasizing aerodynamics and acoustic control. The DN Pro fans feature a three-phase, six-pole motor, contributing to the pro-grade cooling performance.

  • Page 4: Package Contents

    Package Contents Neptune DN120 PRO Single Pack 1. Neptune DN120 PRO Fan x 1 2. Fan Screws x 6 3. Radiator Screws 30 mm x 4 4. Radiator Screws 32 mm x 4 5. PWM Fan Extension Cable 500 mm x 1 Neptune DN140 PRO Single Pack 1.

  • Page 5: Specifications

    212 x 37 x 157 mm 232 x 37 x 177 mm (L x W x H) 8.35 x 1.45 x 6.18" 9.13 x 1.45 x 6.97" Warranty 6 Years * InWin products comply with RoHS regulations. * Specifications may vary based on different regions.

  • Page 6: Cable Information

    Cable Information PWM Fan Cable +12V +12V PWM Fan Extension Cable +12V...

  • Page 7: Installation

    Installation Please make sure the power is off. Install the fans by mounting them in the designated areas. (1) Determine your airflow direction: The following arrow indicates the direction the air will be blowing. (2) Determine your cooling setup and select the right screws: Fan Screws Radiator Screws 30 mm...
  • Page 8 Installation How to daisy-chain fans to a motherboard: 4-Pin (12V, PWM) * Please note that the package contains only one fan. Use PWM fan extension cables for the following reasons only: a. The distance between fans are too far away. b.

  • Page 9: Troubleshooting

    1. Please check your system's power. 2. Please make sure all the connectors are connected properly. 3. For more technical support, please visit InWin Forum at https://forum.in-win.com/ Important Notes 1.Please install the fans by following our instructions. 2.When storing the fans, please keep this product away from high temperatures.
  • Page 10 Copyright © 2023 In Win Development Inc. All Rights Reserved.

This manual is also suitable for:

Neptune dn140 pro
