Assign A Temporary Ip Address - ProSoft Technology RadioLinx RLXIB-IHW-66 Setup Manual

RLXIB-IHW-66 ♦ 802.11a,b,g
Industrial Hotspot
6

Assign a Temporary IP Address

You need the IP address to log into the Radio Configuration/Diagnostic Utility
and configure the radio settings. If the radio is connected to a network with a
DHCP server, the radio may already have an IP address assigned to it.
If a DHCP server is not available, or if you prefer to assign a static IP address,
you can enter a temporary IP here. You will use the Radio Configuration /
Diagnostic Utility to assign a permanent IP address.
To assign a temporary IP Address
1 In IH Browser, click to select the radio.
Tip: If a radio listing does not appear in the window, open the File menu and choose Scan. If you
still do not see a radio listing, refer to Diagnostics and troubleshooting in the RLXIB User Guide.
2 Open the Operations menu, and choose Assign IP. This action opens the
Assign Temporary IP Address dialog box.
3 Accept the dynamically assigned address, and then click OK.
For information, see Radio Access settings.
Page 12 of 20
Assign a Temporary IP Address
Setup Guide
ProSoft Technology, Inc.
May 18, 2009
