Plug In the Cables

You can configure the RLXIB-IHW-66 using the Ethernet port on the underside of
the radio.
If you are connecting to the radio through an Ethernet hub or switch, use the
2 gray (straight-through) cables.
If you are connecting to the radio directly from your PC without going through
an Ethernet hub or switch, you must use the red (crossover) cable and a gray
(straight-through) cable.
Note: After you plug in the Ethernet cable (which supplies both power and connectivity), the radio
performs a startup procedure that includes a self-test, loading the main program, and initializing the
radio. This startup procedure can take up to two minutes.
After the startup procedure has completed successfully, the Power/Status LED
should be green, meaning that the radio has power. The Ethernet LED should
also be green, meaning that the Ethernet connection is working. The RF
Transmit and RF Receive LEDs should blink.
For information on making connections, see Radio power requirements and
Cable specifications.
