- Page 1 Operating instructions Room controller display compact module Art. no. 429 D1 ST ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Telefon: +49 2355 806-0 Telefax: +49 2355 806-204 kundencenter@jung.de 03.08.2023 32408603 j0082408603 www.jung.de...
-
Page 2: Table Of Contents
Room controller display compact module Table of contents Safety instructions ...................... 3 Device components ...................... 3 System information ...................... 3 Intended use ........................ 4 Product characteristics ..................... 4 Operation .......................... 4 Information for electrically skilled persons ................ 6 Mounting and electrical connection................ 6 Commissioning ...................... -
Page 3: Safety Instructions
The device can be updated. Firmware can be easily updated with the Jung ETS Ser- vice App (additional software). 32408603 3 / 12 03.08.2023... -
Page 4: Intended Use
Room controller display compact module The device is KNX Data Secure capable. KNX Data Secure offers protection against manipulation in building automation and can be configured in the ETS project. De- tailed technical knowledge is required. A device certificate, which is attached to the device, is required for safe commissioning. - Page 5 Room controller display compact module ￭ Dim: Long press on button. The dimming process ends when the button is re- leased. ￭ Move Venetian blind: Long press on button. ￭ Stop or adjust Venetian blind: Short press on button. ￭ Call up light scene: Short press on button.
-
Page 6: Information For Electrically Skilled Persons
Room controller display compact module Second operating level In the second operating level the following settings are available in sequence. Some items are not visible, depending on the programming of the device. – Presence mode – Setpoint shift – Basic temperature for Comfort mode –... - Page 7 Room controller display compact module Snapping on the adapter frame The adapter frame is required depending on the switch design range. ￭ With the adapter frame (7) in the correct orientation, snap it from the front onto the module (8) (see figure 2). Note marking TOP =. Mounting and connecting the device Image 2: Mounting the controller module Supporting frame...
- Page 8 Room controller display compact module DANGER! When mounting with 230 V devices under a common cover, e.g. socket outlets, there is a danger of electrical shocks in the event of a fault! Electric shocks can be fatal. Do not install any 230 V devices in combination with a push-button sensor extension module under a common cover! ￭...
-
Page 9: Commissioning
Room controller display compact module (15) Slot for push-button sensor extension module (16) Push-button sensor extension module connecting cable Commissioning Preconditions in secure operation – Secure commissioning is activated in the ETS. – Device certificate entered/scanned or added to the ETS project. A high resolu- tion camera should be used to scan the QR code. -
Page 10: Safe-State Mode
Room controller display compact module Fitting the control surfaces The buttons (10) are available as a complete set of buttons. Individual buttons can be replaced using buttons with icons. The physical address is loaded into the device. ￭ Place the buttons (10) on the device in the correct orientation and snap in with a short push. -
Page 11: Flashing Frequencies Of The Leds
Room controller display compact module Performing a master reset Precondition: The safe-state mode is activated. ￭ Press and hold down the push-button (17) (see figure 4). Then press the push- button (18) for longer than 5 seconds until the operation LED flashes quickly (approx. -
Page 12: Accessories
Cover kit 4-gang Art. no.: ..404 TSA.. Warranty The warranty is provided by the specialist trade in accordance with statutory require- ments. ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Telefon: +49 2355 806-0 Telefax: +49 2355 806-204 kundencenter@jung.de...
