U-Line CLR2060 Features & Benefits

Custom 1/4" Door Panel: 28-5/32" H x 14-1/32" W (71.5 cm x 35.6 cm)
3/4" Full Overlay Panel: 29-7/8" H x 14-3/4" W (75.9 cm x 37.5 cm)
See Overlay Door Panel Preparation Instructions
*WATER INLET
*WATER DRAIN
*POWER CORD
1-3/4
8-1/8
(4.5)
(20.6)
1-5/8
(4.1)
7-3/8
* ON BACK OF UNIT
(18.7)
E X C L U S I V E F E A T U R E S O F É C H E L O N ™
1. High daily ice production and storage capability
BENEFIT: Produces up to 60 pounds of ice per
day and stores up to 30 pounds.
2. An EXCLUSIVE FEATURE of the Échelon™ Series
is an optional full overlay door capability (panel
kit) using a 3/4 inch thick panel
BENEFIT: Provides a fully integrated appearance
with surrounding cabinets. Overlay panel is easily
attached to the door.
3. Automatic electronic control module that controls
daily ice production
BENEFIT: Maximizes the daily ice production by
monitoring and automatically making adjustments
for changes in the ambient room and water temper-
atures. Provides for a consistently shaped ice cube.
14-15/16
(37.8)
34-1/8
(86.7)
FULL
RETRACT
HEIGHT
35-1/8
(89.2)
FULL
EXTEND
HEIGHT
8-1/8
(20.6)
*WATER VALVE
2-15/16
(7.5)
Model CLR2060
A Clear Ice Maker which produces up to 60
pounds of ice per day and stores up to 30
pounds.
24
(61.0)
21-3/4
(55.2)
7
(19.2)
WATER VALVE
FULL
RETRACT
HEIGHT
3-3/8
(8.6)
WATER DRAIN
INCHES (CENTIMETERS)
4. Easy, self-cleaning process
BENEFIT: Eliminates any complicated procedures
or time consuming process in order to clean the ice
maker. Just empty the ice bin, turn the switch to
"Clean," and add the U-Line cleaner fluid after the
water reservoir fills. In approximately 45 minutes the
ice maker has automatically completed a series of
cleaning and rinsing cycles and is ready to start
producing ice once the switch is turned to the "Ice"
position.
5. Quietest ice maker in its class
BENEFIT: Up to twice as quiet during its ice
making and ice storage operation than some
competitive models.
6. Seven (7) inch drain height extending from the
rear of the CLR2060
BENEFIT: Allows for more installation flexibility
in the respect that the higher the drain height the
further the CLR2060 can be located from the gravity
feed drain.
