QUICK START GUIDE
PSoC™ 6 Wi-Fi Bluetooth® Pioneer Kit
CY8CKIT-062-WIFI-BT
Kit contents:
1. PSoC
6 Wi-Fi Bluetooth® pioneer board
TM
2. CY8CKIT-028-TFT display shield
3. USB Type-A to Type-C cable
www.infineon.com/CY8CKIT-062-WIFI-BT
4. Four jumper wires (four inches each)
5. Two proximity sensor wires (five inches each)
6. Quick start guide (this document)
-
Advertisement
Related Manuals for Infineon CY8CKIT-062-WIFI-BT
Summary of Contents for Infineon CY8CKIT-062-WIFI-BT
- Page 1 QUICK START GUIDE PSoC™ 6 Wi-Fi Bluetooth® Pioneer Kit CY8CKIT-062-WIFI-BT Kit contents: 1. PSoC 6 Wi-Fi Bluetooth® pioneer board 4. Four jumper wires (four inches each) 2. CY8CKIT-028-TFT display shield 5. Two proximity sensor wires (five inches each) 3. USB Type-A to Type-C cable 6.
- Page 2 Before you start 1. Set SW5 (located in the middle of the CY8CKIT-062-WIFI- BT board) to the 3.3 V position. 2. Power the board by connecting it to your PC using the provided USB cable through the USB-C connector (J10). 3.
- Page 3 Battery charging indicator (LED6) 22. PSoC 6 VDD selection switch (SW5) KitProg2 USB Type-C connector (J10) 23. Infineon 512-Mbit serial NOR flash memory (S25FL512S, U4) EZ-PD™ CCG3 Type-C Port Controller with PD (CYPD3125-40LQXI, U3) 24. PSoC 6 user LEDs (LED8, LED9) KitProg2 programming mode selection button (SW3) 25.
- Page 4 6 MCU I/Os KitProg3 I/Os Digilent Pmod * Not connected For additional details, see the kit guide available on the Infineon kit webpage. All rights reserved. © 2023 Document number: 002-22582 Rev. *G Date: 09 / 2023 Infineon Technologies AG...
