TAPERED RADAR MAST PTM-R1-1 AND
PTM-R1-2
Part List
PTM-RM
Taper mast
PTM-003848
PTM Wing LH
101817
Ø16 Grommet
60621
M6x20 Hex Head bolt
610825
M8x25 CSK bolt
60510
M5x10mm Pan Head
FLIR M100/200 riser kit
10039
M100-200 plate
60065
M6 Washer
Parts not supplied
A4 M10 Hex Head bolt
suitable for install
PTM-R1-2 only
DPT-R-PLATE-02
X1
Mounting plate
PTM-003782
X1
PTM Wing RH
101804
X2
Ø23 Grommet
60065
X6
M6 Washer
60080
X4
M8 Nut
X4
620260
X1
M6x25mm Sockert head
60060
X12
M6 Nut
A4 M10 Washer
X4
19-07-23 (Issue 1)
PTM-R1-1 only
DPT-R-PLATE-01
X1
Mounting plate
PTM-003863
X1
Cover plate
101818
X3
Tube cap
64004
X12
M10 Shoulder washer
60085
X4
M8 Washer
60068
X6
M6 Nut cover
60702
X12
M6 Nylon washer
UK & International
+44 (0)1392531280
sales@scanstrut.com
X4
Installation Instructions
X1
19008
X2
Base seal
60068
X4
M6 Nut cover
60060
X4
M6 Nut
65058
X4
M5 Shoulder Washer
610625
X12
M6x25mm CSK bolt
X12
For further installation
and warranty information
please visit:
www.scanstrut.com
X1
X6
X6
X4
X6
USA
+1 860 308 1416
usasales@scanstrut.com
