Scanstrut Scanpod Installation Instructions
IMPORTANT
Deck Pods are only compatible with marine electronics devices as stated in the latest Scanstrut Product guide – subject to change
without prior notice.
Use with unapproved products, or overloading, invalidates any warranty.
No liability is accepted for damage caused by incorrect installation.
The installation and assembly must be regularly inspected for evidence of damage or loose parts.
Product has been designed specifically for the mounting of approved marine electronics devices and used under normal boating
DECK POD
conditions.
This product is designed to be fitted to a suitable surface, minimum Ø100mm. Scanstrut does not supply fastenings to fix this
product to the chosen surface. Please choose suitable fastenings for this purpose.
For installations that differ from those stated here, please consult Scanstrut head office.
®
INSTALLATION SOLUTIONS FOR MARINE ELECTRONICS
Advertisement
Table of Contents
Related Manuals for Scanstrut Deck Pod
Summary of Contents for Scanstrut Deck Pod
- Page 1 Scanstrut Scanpod Installation Instructions IMPORTANT Deck Pods are only compatible with marine electronics devices as stated in the latest Scanstrut Product guide – subject to change without prior notice. Use with unapproved products, or overloading, invalidates any warranty. No liability is accepted for damage caused by incorrect installation.
- Page 2 Tools Required Parts List 60540 620645 Lever Components Pod Back 60541 60514 Jigsaw/Spiral Ball Hole Saw ø50-52mm (2") Pod Front Power drill Base Cup Posidriv No. 3 Screwdriver Bracing Plate 60546 60514 60513 60545 60706 4mm Allen Key 3mm Allen Key DRILLING TEMPLATE These fasteners are not supplied.
