- Page 1 Free stand Bath Shower Mixer Fitting instructions Please note: Tap head shown is for illustration purposes only. Please keep these instructions for future reference and request of replacement parts.
-
Page 2: Table Of Contents
We have taken great care to ensure that this product reaches you in perfect condition. However should any parts be damaged or missing please contact your point of purchase. This does not affect your statutory rights. In addition if you require replacement parts your point of purchase will be happy to assist. -
Page 3: Tools Required
Tools required (Tools not supplied) Parts Supplied Description Spout tap assembly Cover Wall screw Rail bracket Wall plug Grub screw Allen key Handset Shower hose Specifications The taps is suitable for use at water supply pressures of 0.5 bar (min.) to 5 bar (max.). This pressure rating is determined by the manufacturer using soft water under test house conditions and may differ to the retailer´s recommendation. -
Page 4: Installation
Installation 1. Prepare the recess and pipework on the floor. Please refer to the dimension drawing on the right. 2. Prepare 2 boards for fixing mixer Hot water body and pipework. Please refer to Cold water the dimension drawing on the right. G½"... - Page 5 5. Driling 3 holes on the board. Note: Only one of the board is need to drill. 6. Secure this assembly to board using wall screw (4, if suitable) and wall plug (6, if suitable). 7. Connect the flexible hose to hot and cold supplies.
- Page 6 10. If watertight, Secure other board to the floor. 11. Gently push the spout(1) into the mixer body. See diagram on the right. 12. Screw the grub screw(7) to mixer body and tighten using an allen key(8).
- Page 7 13. Ensuring the hose washer is in position, attach the conical end of the shower hose(10) to handset(9) and tighten. DO NOT OVER TIGHTEN. Ensuring the hose washer is in position, attach the non-conical end of the shower hose(10) to outlet of the mixer body.
-
Page 8: Aftercare
Aftercare Cleaning the cartridge (if water dripping from tap) Before carrying out any maintenance, turn off the mains water supply. If unsure contact a qualified tradesman. Remove the cap, grub screw, handle and cover. Remove the retaining nut using a suitable spanner, pull the cartridge from the mixer body, clean thoroughly under cold water to remove any build up of limescale or debris.
