Introduction

The purpose of this manual is to guide installers, operators and technicians through the

operation of EVO™ 200 and EVO™ 400 automatic tank gauges (ATGs). EVO™ 200 and EVO™ 400

ATGs incorporate the monitoring and alarm capabilities of preceding automatic tank gauges

with advanced technologies to supply tank and level data more accurately and efficiently. This

manual is also designed to introduce technicians to the optional LCD Graphical User Interface,

which is used as an input device to program system configuration and maintain all applications

from the front panel of the console. Overall safety issues, troubleshooting information, start-up

procedures, warranty, service and return policies, as defined in this manual, must be followed.

EVO™ 200 and EVO™ 400 ATGs consist of an open architecture console that can run multiple

Fuel Management Applications simultaneously. It typically contains a color LCD touch screen

user interface, but it can also be operated by a web-based remote interface. Magnetostrictive

Liquid Level Probes inside of the tanks provide the console with inventory and leak detection

information. A variety of optional sensors can be used to monitor containment spaces.

LED Indicators: Three LEDs below the front panel give an "at-a-glance" indication of the

system status. These LEDs are standard on all systems. The green Power LED indicates that the

system power is on. The yellow Warning LED gives indication that the console has detected a

malfunction or condition that has been deemed a Warning. The red Alarm LED indicates that the

system has detected an alarm condition.

LCD Touch Screen: The color LCD touch screen is the most commonly used user interface for the

Fuel Management System. This bright and colorful display allows easy viewing in any lighting

condition. Touching certain buttons or segments of the screen will allow access to menus or

more detailed information. Do not use sharp or pointed objects to operate the touch screen or

damage may result. If improper operation of the touch screen is noted, it may be necessary to

calibrate the touch screen. Please refer to the Routine Maintenance chapter of this manual for

calibration procedures.
