Delta MultiChoice 17 Series Manual page 2

SHOWER HEAD(S)
POMME(S) DE DOUCHE
CABEZA(S) DE REGADERA
T17059▲ T17259▲
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
6 1/2"
(165 mm)
AF Dia.
= Adjustable Full Spray (AF)
AH O
2
= Adjustable H
8" (203 mm)
18" (457 mm)
max.
CF
= Crossing Full Spray (CF)
CFM
= Crossing Full Spray w/Massage (CFM)
▲ Designate Proper Finish Suffix
RP70175
H 2 O Shower Head
▲
FB
2 39/64"
= Full Body Spray (FB)
(66 mm)
Full Spray
FM
= Fast Massage (FM)
5 13/32"
(137 mm)
FSM
= Full Spray w/Massage (FSM)
RP77992 Available Extension Kit
HE
= High-Efficiency Spray (HE)
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
H O
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
2
www.deltafaucet.com for finish options and product availability.
= H Okinetic
™
DSP-B-T17059 Rev. I
2
SHOWER HEAD(S)
POMME(S) DE DOUCHE
CABEZA(S) DE REGADERA
T17459▲ T17259-▲LHD
Face of plasterguard
should be flush with
finish wall line
Okinetic ™ Spray (AH
2 2
min.
2 3/4"
(70 mm)
RP73371 Pull-Up Diverter
▲
SHOWER HEAD(S)
POMME(S) DE DOUCHE
CABEZA(S) DE REGADERA
3 3/8"
(86 mm)
Spray (H O)
2
T17459-▲LHD
C/L
Supply
Lines
P
= Pause (P)
Supply
M
O) = Massage Spray (M)
SD
= Soft Drench Spray (SD)
SF
= Soft Full Spray (SF)
SM
= Slow Massage (SM)
3 3/16"
(81 mm)
SDF
= Soft Drench w/Full Spray (SDF)
5 1/4"
(133 mm)
SDM
= Soft Drench Spray w/Massage (SDM)
SR
= Shampoo Rinsing Spray (SR)
SRM
= Shampoo Rinsing Spray w/Massage (SRM)
TUB AND SHOWER
FAUCET TRIM
®
■ Trinsic Series
■ Valve Only (T17059)
■ Shower Only (T17259)
■ Tub/Shower (T17459)
FEATURES:
• Monitor ® 17 Series pressure balanced bath mixing
valve with trim
• Single function H 2 Okinetic ® Technology shower head
STANDARD SPECIFICATIONS:
• Maintains a balanced pressure of hot and cold water even
when a valve is turned on or off elsewhere in the system
• For use with MultiChoice ® Universal rough valve body
(R10000 Series)
• Back-to-back installation capability
• Solid brass forged body
• Lever volume control handle; temperature adjustment dial
• Field adjustable to limit handle rotation into hot water zone
• Maximum dial rotation adjustable between 90° and 180°
• All parts replaceable from the front of the valve
• Maximum 1.75 gpm @ 80 psi, 6.6 L/min @ 550 kPa
• Tub port maximum flow rate 6.2 gpm @ 60 psi with
R10000-UNBX
• Shower arm overall horizontal length = 5 1/2" (138 mm),
including threaded ends
• Red/blue pad print temperature indicators on the temperature
adjustment dial
• 1/2" CWT slip-on spout adapter
• "-LHD" models indicate less showerhead
• Stem extension kit RP77992 can be ordered to allow for
an additional 1 3/4" wall thickness. RP77992 ships with
chrome escutcheon screws. For special finishes also
order RP12630 escutcheon screws in desired finish.
WARRANTY
• Parts and Finish - Lifetime limited warranty; or for
commercial purchasers, 10 years for multi-family
residential (apartments and condominiums) and
5 years for all other commercial uses, in each case
from the date of purchase.
• Electronic Parts and Batteries (if applicable) - 5
years from the date of purchase; or for commercial
purchasers, 1 year from the date of purchase. No
warranty is provided on batteries.
COMPLIES WITH:
•
ASME A1 12.18.1 / CSA B125.1
•
ASSE 1016
Indicates compliance to
ICC/ANSI A117.1- Valve control only
•
®
EPA WaterSense
Delta Faucet Company
55 E. 111th Street, Indianapolis, IN 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2018 Delta Faucet Company
