Summary of Contents for Delta MultiChoice 13 Series

  • Page 2 Failure to re-adjust the valve please consult the installation instruction sheet provided with this valve or call 1-800-345-DELTA. may result in hot water burns or extreme cold resulting from variations in...
  • Page 3 When this type of page 14 (17T series) and if still uncertain, call us device shuts off the water flow, it can defeat at 1-800-345-DELTA. the ability of the valve to balance the hot and After installation and adjustment, you must affix cold water pressures.
  • Page 4 1-800-345- & business usage, whose purchasers are DELTA (in the U.S. and Canada) or by writing to: hereby extended a five year limited warranty from the date of purchase, with all other terms of...

  • Page 5: Cartridge Installation

    13 / 14 Series Installation Cartridge Installation Turn off water supplies. Remove Rotate the cartridge (1) so the words “hot side” (2) appear on the left. Insert cover (1), bonnet nut (2) and test cap (3) cartridge into valve body as shown. Make from the body.
  • Page 6 13 / 14 Series Installation Showerhead and Tub Spout Installation FOR SHOWERHEAD INSTALLATION: Connect top outlet (1) to shower arm (2) with proper fittings. To prevent damage to finish on shower arm, insert wall end of shower arm into shower flange (3) before screwing arm into riser connection.
  • Page 7 13 / 14 Series Installation 13 / 14 Series Installation Adjusting the Rotational Limit Stop Hotter 1st Position Rotational Limit Stop IMPORTANT: for a comfortable bath or shower is typically The Rotational Limit Stop is used to limit the between 90°F - 110°F. amount of hot water available such that, if set •...

  • Page 8: Trim Installation

    13 / 14 Series Installation Trim Installation Slide O-ring (1) over cartridge and the If your model requires a spacer (1), insert bonnet nut (2). The O-ring, which acts as it into the sleeve (2) and push it to the a spacer to steady the sleeve, should rest front.

  • Page 9: Series Installation

    17 Series Installation Cartridge Installation Turn off water supplies. Remove Insert adapter assembly (1) into valve cover (1), bonnet nut (2) and test cap (3) body. Make sure the adapter assembly from the body. If this is not a thin wall is correctly positioned and is pressed all mounting, the entire plasterguard (4) the way down inside body.
  • Page 10 17 Series Installation Showerhead and Tub Spout Installation FOR SHOWERHEAD INSTALLATION: Connect top outlet (1) to shower arm (2) with proper fittings. To prevent damage to finish on shower arm, insert wall end of shower arm into shower flange (3) before screwing arm into riser connection.
  • Page 11 17 Series Installation Trim Installation Slide O-ring (1) over cartridge and the Slide the sleeve (1) over the cartridge, bonnet nut (2). The O-ring, which acts as body and O-ring. Ensure sleeve is properly a spacer to steady the sleeve, should rest positioned over the front of cartridge.
  • Page 12 17 Series Installation Installation and Adjustment of the Rotational Limit Stop Hotter Place the temperature control knob (1) on volume handle and rotate to the mixed position (if required). DO NOT SECURE WITH SCREW. Turn on water supplies; Colder let the water run until both hot and cold water is as hot/cold as possible.
  • Page 14 17T Series Installation Showerhead and Tub Spout Installation FOR SHOWERHEAD INSTALLATION: Connect top outlet (1) to shower arm (2) with proper fittings. To prevent damage to finish on shower arm, insert wall end of shower arm into shower flange (3) before screwing arm into riser connection.
  • Page 15 17T Series Installation Valve Trim Installation Slide O-ring (1) over cartridge and the Slide the sleeve (1) over the cartridge, bonnet nut (2). The O-ring, which acts as body and O-ring. Ensure sleeve is properly a spacer to steady the sleeve, should rest positioned over the front of cartridge.

  • Page 16: Cleaning And Care

    17T Series Installation Installation and Adjustment of the Temperature Knob Failure to do so may cause injury. Adjust temperature limit stop! Turn on than 120° or the lower temperature water supplies; let the water run at both mandated by your local plumbing code). full hot and full cold to ensure the water is Remove the temperature knob and replace running as hot/cold as possible.
  • Page 17 13/14 Series Maintenance Faucet leaks from tub spout/showerhead: a screwdriver. Place handle on stem and rotate counterclockwise approximately 1/4 turn after the SHUT OFF WATER SUPPLIES. stop has been contacted. Lift valve cartridge out Replace seats and springs–Repair Kit RP4993. Check condition of lower O-rings and of body.
  • Page 18 MultiChoice™ 13/14 Monitor 1300/1400 Monitor 1300/1400 ® ® Longer Shorter Lower Housing Shorter Lower Housing Lower Housing White White Grey Blue Off White Blue Off White Order RP46074 to Order RP19804 to Order RP19804 to Replace Cartridge. Replace Cartridge. Replace Cartridge. Grey Upper Cap...
