Write purchased model number here.
Table of Contents:
Warranties ...............................................................................   P age 2
Installation Instructions ...........................................................   P ages     3 - 11
Clean and care.........................................................................   P age 12
Maintenance ............................................................................ Page 12
Cartridge Summary Reference Sheet .....................................     P age 12
For additional replacement parts,
visit www.deltafaucet.com/service-parts
THIS VALVE MEETS OR EXCEEDS THE
FOLLOWING STANDARDS: ASME A112.18.1/
CSA B125.1 and ASSE 1016 (Type -P- or -T-).
CAUTION: This system/device must be set by the
installer to ensure safe, maximum temperature.
Any change in the setting may raise the discharge
temperature above the limit considered safe and
may lead to hot water burns.
NOTICE TO INSTALLER: CAUTION!–As the
installer of this valve, it is your responsibility
to properly INSTALL and ADJUST this valve
per the instructions given. This valve does
not automatically adjust for inlet temperature
changes, therefore, someone must make the
necessary Rotational Limit Stop adjustments
at the time of installation and further adjustments
may be necessary due to seasonal water
temperature change. YOU MUST inform the
owner/user of this requirement by following
the instructions. If you or the owner/user are
unsure how to properly make these adjustments
please refer to page 7 and if still uncertain, call
us at 1-800-345-DELTA.
After installation and adjustment, you must affix
your name, company name and the date you
09/25/2023
MultiChoice
Installation Instructions
Owners Manual
17 Series
You May Need
adjusted the Rotational Limit Stop to the caution
label provided and apply or attach the label to
the back side of the closest cabinet door and the
warning label to the water heater. Leave this
Instruction Sheet for the owner's/user's
reference.
WARNING: This pressure balanced or
thermostatic bath valve is designed
to minimize the effects of outlet water
temperature changes due to inlet pressure
changes, commonly caused by dishwashers,
washing machines, toilets and the like. It may
not provide protection from hot water burns
when there is a failure of other temperature
controlling devices elsewhere in the
plumbing system, if the rotational limit stop
is not properly set or if the hot water
temperature is changed after the settings are
made or if the water inlet changes
due to seasonal changes.
WARNING: Do not install a shut-off device on
either outlet of this valve. When this type of
device shuts off the water flow, it can defeat
the ability of the valve to balance the hot and
cold water pressures.
1
®
Valve Trim
X00107529
107529 Rev. G

Advertisement

loading
Need help?

Need help?

Do you have a question about the MultiChoice 17 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Delta MultiChoice 17 Series

  • Page 1 WARNING: Do not install a shut-off device on please refer to page 7 and if still uncertain, call either outlet of this valve. When this type of us at 1-800-345-DELTA. device shuts off the water flow, it can defeat After installation and adjustment, you must affix...
  • Page 2 ® MultiChoice Rough-In Installation (When your product requires) SHUT OFF WATER SUPPLIES. must be flush or subflush 3/8" to Consider the type and thickness of your finished wall. Mount body using the two finished wall before placing your stringer stringer mounting holes (4) on the bracket. back plate.
  • Page 3 Copper Tubing Iron Pipe Connect valve body to water supplies using If you are making a back to back or the proper fittings for your valve body type reverse installation (hot on right and (copper tubing, iron pipe or Pex). Note: (1) is cold on left) install the valve body as the cold inlet port and (2) is the hot inlet described, but the water supply lines will...
  • Page 4 Connect top outlet (1) to shower pipe with proper fittings. Connect bottom outlet (2) to tub spout pipe with proper fittings. Pipe (3) between valve body and tub spout must be a minimum of 1/2" (13 mm) copper pipe or 1/2" (13 mm) iron pipe in a straight drop no less than 8"...
  • Page 5 Cartridge Installation Turn off water supplies. Remove bonnet Insert adapter assembly (1) into valve nut (1) and test cap (2) from the body. If body. Make sure the adapter assembly this is not a thin wall mounting, the entire is correctly positioned and is pressed all plasterguard (3) may be removed.
  • Page 6 Shower Head and Tub Spout Installation FOR SHOWER HEAD INSTALLATION: Connect top outlet (1) to shower arm (2) with proper fittings. To prevent damage to finish on shower arm, insert wall end of shower arm into shower flange (3) before screwing arm into riser connection.
  • Page 7 FOR TUB SPOUT INSTALLATION: Refer to the installation instructions supplied with your spout. Do not connect deck mount spouts to in-wall valves. Do not use hand showers connected in lieu of a tub spout to a tub/shower valve. Do not use PEX tubing for tub spout drop.
  • Page 8 Ensure sleeve is properly positioned over the front of cartridge. Note: Adust for up to 1" thick wall. For thick wall installation, visit delta faucet website, check "view technical specification" of the models you bought, order the appropriate thick wall installation kit RP to get additional 1 3/4"...
  • Page 9 Installation and Adjustment of the Rotational Limit Stop Place the temperature control knob (1) on Hotter volume handle and rotate to the mixed position (if required). DO NOT SECURE WITH SCREW. Turn on water supplies; let the water run until both hot and cold water is as hot/cold as possible.
  • Page 10 Place volume handle (11) onto cartridge. Seat stop (13) into volume handle, place adapter (14) into handle and tighten screw (15). Thread cover (12) onto handle. Place temperature handle assembly (16) onto cartridge and drive set screw (17). Install adapter (1) over valve stem (2) and secure it with screw (3). Install washer (4) onto handle (5), slide handle onto adapter and secure it with screw (6), then cover set screw with handle button (7).
