Bedienung und Installation
SNU 10 Plus  / SNU 10 Plus AU /
SNU 10 Plus GB
Kleinspeicher (drucklos)
2
Small water heater (non-pressuri-
sed)
11
Kleine boiler (drukloos)
20
Malé zásobníky (beztlakové)
28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SNU 10 Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for STIEBEL ELTRON SNU 10 Plus

  • Page 1 Bedienung und Installation SNU 10 Plus  / SNU 10 Plus AU / SNU 10 Plus GB Kleinspeicher (drucklos) Small water heater (non-pressuri- sed) Kleine boiler (drukloos) Malé zásobníky (beztlakové)
  • Page 2: Table Of Contents

    13.1 Dimensions and connections of the SNU 10 Plus (all versions)..........17 13.2 Wiring diagram..........17 13.3 Heat-up diagram..........17 13.4 Energy consumption data......... 17 13.5 Data table ............17 14 Guarantee ..............18 15 Environment and recycling........19 www.stiebel-eltron.com SNU 10 Plus |...
  • Page 3: Special Information

    Read these instructions carefully before using the which the warning notice refers appliance and retain them for future reference. Pass on these instructions along with the appliance 3.1.3 Key to symbols as necessary. Symbol Type of risk Injury | SNU 10 Plus www.stiebel-eltron.com...
  • Page 4: Intended Use

    During installation, the water connections on the A non-pressurised tap must be used for open vented operation appliance must point upwards. of the appliance. Stiebel Eltron offers a wide range of suitable taps. Safety instructions – There is a risk of scalding at outlet temperatures in excess Installation (qualified contractors) of 43 °C.
  • Page 5: Appliance Installation

    – R.h. side blue = "Cold water inlet" WARNING – L.h. side red = "DHW outlet" Electrocution Ensure that the appliance is connected to the earth u Secure the water connections from the tap to the appliance. conductor. | SNU 10 Plus www.stiebel-eltron.com...
  • Page 6: Setting A Permanent Temperature Limit

    Isolate the appliance from the power supply. u Undo the fittings on the water connections. u Remove the appliance from the wall mounting bracket. u Allow the appliance to drain into a sink with the water con- nections pointing downwards. www.stiebel-eltron.com SNU 10 Plus |...
  • Page 7: Opening The Appliance

    NOTICE:  The connecting cable must only be replaced with an original spare part by a qualified contractor. Positioning the temperature sensor in its protective pipe u When replacing the temperature controller, guide the tem- perature sensor into its protective pipe. | SNU 10 Plus www.stiebel-eltron.com...
  • Page 8: Specification

    13 Specification The heat-up period depends on the degree of scaling and resid- 13.1 Dimensions and connections of the SNU 10 Plus ual heat. For the heat-up time for a cold water supply at 10 °C and a maximum temperature setting, see the diagram.
  • Page 9: Guarantee

    12. We may reject your warranty claim if: Who gives the warranty – The unit was not installed by registered and qualified The warranty is given by Stiebel Eltron (Aust) Pty Ltd (A.B.N. 82 tradespeople. 066 271 083) of 294 Salmon Street, Port Melbourne, Victoria, 3207 –...
  • Page 10: Environment And Recycling

    19. The Stiebel Eltron warranty for the unit is in addition to any rights and remedies you may have under the Australian Consumer Law. 15 Environment and recycling We would ask you to help protect the environment.
  • Page 11 Comfort through Technology STIEBEL ELTRON International GmbH Dr.-Stiebel-Straße 33 / 37603 Holzminden / Germany info@stiebel-eltron.com / www.stiebel-eltron.com 4 0 1 7 2 1 3 5 3 2 9 7 2...
