  • Page 1 Bedienung und Installation Operation and installation Gebruik en Installatie Obsluha a instalace SNU 5 Plus  / SNU 5 Plus AU / SNU 5 Plus GB / SNU 5 Plus 1 kW Kleinspeicher (drucklos) Small water heater (non-pressuri- sed) Kleine boiler (drukloos) Malé zásobníky (beztlakové)
  • Page 2: Table Of Contents

    13.1 Maße und Anschlüsse ........9 13.2 Elektroschaltplan..........9 13.3 Aufheizdiagramm..........9 13.4 Angaben zum Energieverbrauch....... 9 13.5 Datentabelle............. 9 14 Kundendienst und Garantie........10 15 Umwelt und Recycling..........11 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 3: Besondere Hinweise

    Art der Gefahr Verletzung Lesen Sie diese Anleitung vor dem Gebrauch sorg- fältig durch und bewahren Sie sie auf. Geben Sie die Anleitung ggf. mit dem Gerät weiter. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 4: Bestimmungsgemäße Verwendung

    Schützen Sie das Gerät und die Armatur vor Frost. – Warnung - Um die Sicherheit dieses Geräts zu gewährleis- ten, muss es gemäß den Anweisungen des Herstellers in- stalliert, betrieben und gewartet werden. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 5: Montage (Fachkraft)

    HINWEIS: Achten Sie darauf, dass die Wasseranschlüsse bei der Montage nicht geknickt werden. Vermeiden Sie Zugspannung beim Einbau. Inbetriebnahme (Fachkraft) HINWEIS:  Stellen Sie die Spannungsversorgung erst dann her, wenn das Gerät vollständig mit Wasser befüllt ist! www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 6: Gerät Mit Wasser Befüllen

    Wasserleitung sind nicht geschützt empfohlene Energiesparstellung ECO (ca. 60 °C), geringe Wasser- steinbildung 85 maximal einstellbare Temperatur HINWEIS:  Die Fachkraft kann eine dauerhafte Temperaturbe- grenzung am Gerät vornehmen. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 7: Reinigung

    Befestigungsschraube des Begrenzungsrings und u Ziehen Sie den Begrenzungsring ab. an dem Schutzleiterkontakt des Anschlusskabels. Anschlusskabel tauschen HINWEIS: Das Anschlusskabel darf nur von einer Fachkraft mit einem originalen Ersatzteil ersetzt werden. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 8: Temperaturfühler Im Schutzrohr Positionieren

    Wenn Sie die Ursache nicht beheben können, rufen Sie eine Fachkraft. u Teilen Sie der Fachkraft zur besseren und schnelleren Hilfe die Nummer vom Typenschild mit. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 9: Technische Daten

    Nennstrom 2 4,35 Nennstrom 3 4,55 Absicherung 1 Absicherung 1 Absicherung 1 Phasen 1/N/PE 1/N/PE Frequenz 50-60 50-60 D0000105875 Einsatzgrenzen Temperatureinstellbereich °C 35 – 85 °C 35 – 85 °C www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 10: Kundendienst Und Garantie

    Diese Rechte werden durch unsere Garantie gesetzlichen Gewährleistungsansprüche des Endkunden. Die nicht eingeschränkt. Die Inanspruchnahme solcher gesetzlichen gesetzlichen Gewährleistungsansprüche gegenüber den sonsti- Rechte ist unentgeltlich. gen Vertragspartnern des Endkunden sind durch unsere Garan- | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 11: Umwelt Und Recycling

    Rücknahme- und Entsorgungskonzept für die um- weltschonende Aufarbeitung der Verpackungen. Überlassen Sie die Transportverpackung dem Fachhandwerker beziehungsweise dem Fachhandel. Entsorgen Sie Verkaufsverpackungen über eines der Dualen Systeme in Deutschland. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 12 13.1 Dimensions and connections ......18 13.2 Wiring diagram..........18 13.3 Heat-up diagram..........19 13.4 Energy consumption data......... 19 13.5 Data table ............19 14 Guarantee ..............19 15 Environment and recycling........20 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 13: Special Information

    Pass on these instructions along with the appliance 3.1.3 Key to symbols as necessary. Symbol Type of risk Injury www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 14: Intended Use

    – Never subject the appliance to water pressure. The tap out- let has a vent function. Scale build-up can block the outlet and subject the appliance to pressure. – Never block the tap outlet. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 15: Appliance Installation

    Commissioning may only be carried out by a qualified contractor in accordance with safety regulations. D0000105765 Filling the appliance with water D0000049325 u Open the cold water inlet of the distribution board. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 16: Electrical Connection

    Undo the two screws securing the limiting ring in the cas- ing. u Re-insert the limiting ring with the required temperature limit. u Secure the limiting ring in the casing with the screws. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 17: Draining The Appliance

    After descaling, flush the heating element with clear water. No voltage at the ap- Check the plug / fuses Reassemble the appliance. pliance. in the distribution board. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 18: Troubleshooting (Installers)

    Isolate the appliance from the power supply by removing the plug or by switching off the MCB in the distribution board. u Drain the appliance (see chapter Draining the appliance [} 17] ). D0000105875 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 19: Heat-Up Diagram

    Stiebel Eltron Warranty for Small Water Heaters Mixed water amount 40 °C Who gives the warranty (10 °C/65 °C) The warranty is given by Stiebel Eltron (Aust) Pty Ltd (A.B.N. 82 Electrical data 066 271 083) of 294 Salmon Street, Port Melbourne, Victoria, 3207 (“we”, “us” or “our”).
  • Page 20: Environment And Recycling

    Rating Label. 19. The Stiebel Eltron warranty for the unit is in addition to any rights and remedies you may have under the Australian Consumer Law. 15 Environment and recycling We would ask you to help protect the environment.
  • Page 21 Montageschablone | Installation Template...
  • Page 23 95 mm...
  • Page 24 Montageschablone | Installation Template...
  • Page 25 13.1 Afmetingen en aansluitingen......27 13.2 Elektrisch schakelschema ......... 28 13.3 Verwarmingsgrafiek......... 28 13.4 Gegevens over het energieverbruik ....28 13.5 Gegevenstabel..........28 14 Garantie..............28 15 Milieu en recycling............ 29 www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 26: Bijzondere Info

    Lees deze handleiding voor gebruik zorgvuldig door genegeerd. Maatregel(en) voor het afwenden van het ge- en bewaar deze. vaar. Handelingsstap waarop de waarschuwing betrekking Overhandig de handleiding eventueel met het toe- heeft stel. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 27: Reglementair Gebruik

    Stiebel Eltron biedt een groot assortiment aan Mogelijke materiële schade geschikte kranen aan. – Vorst kan het toestel en de aangesloten kraan vernielen. Bescherm het toestel en de kraan tegen vorst. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 28: Montage (Installateur)

    Zorg ervoor dat er tijdens het inbouwen geen trekspanning ontstaat. Ingebruikname (installateur) LET OP: Breng de spanningsvoorziening pas tot stand, wanneer het toestel volledig met water is gevuld! | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 29: Toestel Met Water Vullen

    ECO (ca. 60 °C), weinig vorming van ketelsteen 85 maximaal instelbare temperatuur LET OP:  De installateur kan een permanente temperatuurbe- grenzing op het toestel instellen. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 30: Reiniging

    Trek de begrenzingsring van het toestel. Aansluitkabel vervangen LET OP: Laat de aansluitkabel altijd door een erkende installa- teur vervangen door een origineel vervangingsonderdeel. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 31: Plaats De Temperatuursensor In De Dompelbuis

    Harde kookgeluiden in Er heeft zich kalk afge- Ontkalk het toestel. voer het toestel. zet in het toestel. Warmwateruit- Buitendraad G 3/8 A loop Wandbevestiging Hoogte Gatafstand horizontaal mm www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 32: Elektrisch Schakelschema

    SNU 5 Plus SNU 5 Plus verlenen wij geen garantie. Een eventueel door de importeur 1 kW verzekerde garantie blijft onverminderd van kracht. 204972 204973 Hydraulische gegevens | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 33: Milieu En Recycling

    Milieu en recycling 15 Milieu en recycling Wij verzoeken u ons te helpen ons milieu te beschermen. Doe de materialen na het gebruik weg overeenkomstig de nationale voorschriften. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 34 13.3 Diagram ohřevu ..........36 13.4 Údaje ke spotřebě energie........ 36 13.5 Tabulka s technickými údaji ......37 14 Záruka ..............37 15 Životní prostředí a recyklace........37 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 35: Zvláštní Pokyny

    Informace pro Austrálii a Nový Zéland Úraz Instalace tohoto přístroje musí být v souladu s před- pisy Plumbing Code of Australia (PCA) a New Ze- aland Building Code. Úraz elektrickým proudem Popálení, opaření www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 36: Použití V Souladu S Určením

    řovat nahoru. nací hodiny, bude mít za následek neúmyslnou deaktivaci bezpečnostního omezovače teploty. Přístroj nesmí být při- pojen k elektrickému obvodu, který je určitým zařízením pravidelně spínán a odpojován. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 37: Montáž Přístroje

    – Vpravo modrá = „Přívod studené vody“ Dávejte pozor na to, že přístroj musí být připojen k ochrannému vodiči. – Vlevo červená = „Výstup teplé vody“ u Pevně přišroubujte připojení k rozvodům vody armatury k přístroji. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 38: Trvalé Nastavení Omezení Teploty

    Odpojte přístroj od síťového napětí. u Povolte šroubení připojení k rozvodům vody. u Přístroj sejměte z nástěnného držáku. u Přístroj s připojeními k rozvodům vody orientovanými smě- rem dolů nechejte vypustit nad dřezem. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 39: Otevření Přístroje

    (> 0,4 l/min). voda. u Pokud nemůžete příčinu odstranit, zavolejte odborníka. u K získání lepší a rychlejší pomoci sdělte odborníkovi číslo z typového štítku. D0000105873 u Odmontujte přípojku „přítok studené vody“. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 40: Odstraňování Poruch (Odborník)

    (ErP). SNU 5 Plus SNU 5 Plus 1 kW 204972 204973 Výrobce STIEBEL ELTRON STIEBEL ELTRON Zátěžový profil Třída energetické účinnosti Energetická účinnost D0000105876 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 41: Tabulka S Technickými Údaji

    Materiál tepelné izolace EPS + VIP EPS + VIP Materiál krytu/skříně Plast Plast Barva Bílá Bílá Přípojky Přípojka vody G 3/8 A G 3/8 A Rozměry Hloubka Výška Šířka Hmotnosti Hmotnost www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
  • Page 42 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
  • Page 43 SNU 5 Plus | AU | GB | 1 kW |...
  • Page 44 Comfort through Technology STIEBEL ELTRON International GmbH Dr.-Stiebel-Straße 33 / 37603 Holzminden / Germany info@stiebel-eltron.com / www.stiebel-eltron.com 4 0 1 7 2 1 3 5 3 2 8 5 9...
