- Page 1 Installation and Operating Instructions Side Channel Blowers Samos SE 0045 - 1105 D/D2 Busch Produktions GmbH Schauinslandstr. 1 79689 Maulburg Germany 0870133372 / 100512 / Original instructions / Modifications reserved...
-
Page 2: Table Of Contents
Technical Data......20 Busch – All over the World in Industry ....21... -
Page 3: Product Description
Busch. The allowed media and operational limits (Ú page 3: Product De- The gas shall be free from vapours that would condensate under the scription) and the installation prerequisites (Ú... -
Page 4: Transport
VCI-products may attack the surfaces of plastics and elastomers. Seek rolled corrugated cardboard: advice from your local packaging dealer! Busch uses CORTEC ◆ Remove the corrugated cardboard from the box VCI 126 R film for the overseas packaging of large equipment. -
Page 5: Mounting Position And Space
Seek advice from your Busch representative! In case the vacuum shall be maintained after shutdown of the side channel blower: ◆... -
Page 6: Electrical Connection / Controls
In case the length of the pressure line exceeds 2 m it is prudent to use larger line sizes in order to avoid a loss of efficiency and an overload of the side channel blower. Seek advice from your Busch representative! ● Make sure that the pressure line either slopes away from the side... -
Page 7: Setting The Relief Valve
In case of allowed differential pressure more than 100 hPa (=mbar): and is permissible only after prior consultation with Busch. ◆ Set the relief valve (II) such that the pressure gauge indicates a... -
Page 8: Maintenance
Busch service. Danger to health during inspection, cleaning or replacement of filters. -
Page 9: Removal From Service
Busch service will only accept side channel blowers that come with a completely filled in and legally binding signed “Declaration of Contam- ination” (form downloadable from www.busch-vacuum.com). Removal from Service Temporary Removal from Service ● Prior to disconnecting pipes/lines make sure that all pipes/lines are... -
Page 10: Troubleshooting
Long suction, discharge or pressure line with Use larger diameter too small diameter Internal parts are worn or damaged Repair the side channel blower (Busch service) The gas conveyed by the side channel blower Process components evaporating under vac- Check the process, if applicable... - Page 11 Try to turn the drive motor with the side channel blower by hand If the side channel blower is blocked: Repair the side channel blower (Busch service) The drive motor is defective Replace the drive motor (Busch service) The side channel blower is blocked...
- Page 12 Insufficient gas transfer Vacuum operation: Provide a vacuum relief valve Pressure operation: Provide a pressure relief valve Mains frequency or voltage outside tolerance Provide a more stable power supply range Adjust, repair or replace, respectively In case a vacuum relief valve/regulating system is installed: The vacuum relief valve/regulating system is misadjusted or defective...
-
Page 13: Exploded Views And Spare Parts Lists
Exploded Views and Spare Parts Lists Exploded Views and Spare Parts Lists SE 0045 - 1105 D/D2 page 13 0870133372 / 100512... - Page 14 SE 0085 D Pos. Part Part no. Housing 0247 132 953 Shaft seal ring 0487 000 008 Impeller 0285 107 555 Washer 0460 000 324 Hex head screw/lock washer 0947 127 451 — — — Cylinder screw 0413 000 121 Hex nut 0420 000 044 Cover...
- Page 15 Exploded Views and Spare Parts Lists SE 0045 - 1105 D/D2 page 15 0870133372 / 100512...
- Page 16 SE 1105 D Pos. Part Part no. Housing 0247 132 958 Cover 0246 132 961 Cylinder screw 0413 117 479 Shaft seal ring 0487 000 142 Impeller 0285 113 131 Washer 0460 132 960 Hex head screw 0410 000 331 Cylinder screw 0413 000 521 Hex nut...
-
Page 17: Se 0085 - 0315 D2
Exploded Views and Spare Parts Lists SE 0045 - 1105 D/D2 page 17 0870133372 / 100512... - Page 18 SE 0085 D2 Pos. Part Part no. Housing 0247 132 953 Shaft seal ring 0487 000 008 Housing 0247 132 954 Impeller 0285 107 555 Washer 0460 000 324 — — — — — — Bushing 0460 125 814 Hex head screw/lock washer 0947 127 451 —...
-
Page 19: Ec-Declaration Of Conformity
Note: This Declaration of Conformity and the -mark affixed to the nameplate are valid for the side channel blower within the Busch-scope of de- livery. When this side channel blower is integrated into a superordinate machinery the manufacturer of the superordinate machinery (this can be the operating company, too) must conduct the conformity assessment process acc. -
Page 20: Technical Data
Technical Data For motor connection parameters see nameplate single stage Max. differential pressure Connection Frequency Volume flow Motor Nominal speed Sound pressure [hPa = mbar] Type inlet, Weight [kg] [Hz] [m³/h] [kW] [min level [db(A)] outlet vacuum pressure 0.37 2850 SE 0085 D G 1¼... -
Page 21: Busch - All Over The World In Industry
