True TDB-24-48-1-G-1 Specifications

St. Charles Industrial Center • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# (636)272-9471
Model:
TDB-24-48-1-G-1
ROUGH-IN DATA
Model Doors
TDB-24-48-1-G-1 2
† 3
Depth does not include 1 /
8
*
Height does not include 15
T R
RUE EFRIGERATION
TM
MADE IN
U.S.A.
®
SINCE 1945
1/06
TRUE FOOD SERVICE
EQUIPMENT, INC.
24" Back Bar/Direct Draw Beer Dispenser
Combination Door
Capacity
left door right door
1
/ 12 oz.
2
Barrels Cans Shelves
1 245 2
" (35 mm) for door handle.
1
/ " (388 mm) for draft arm.
4
APPROVALS:
R
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
Chart dimensions rounded up to the nearest
Cabinet Dimensions
(inches)
(mm)
† * HP
L D H
1 1 5 1
49 / 24 / 35 / /
8 4 8 3
1
1248 616 905 /
3
Qty:
TDB-24-48-1-G-1
True's back bar/direct draw combination
coolers are designed with enduring
quality and value. Our commitment to
using the highest quality materials and
oversized refrigeration assures colder
product temperatures and years of
trouble free service.
Oversized, factory balanced,
refrigeration system holds 33°F to 38°F
(.5°C to 3.3°C).
Exterior - heavy duty, wear resistant
laminated black vinyl front and sides.
Matching black aluminum back. All
stainless steel counter top.
Interior - 300 series stainless steel fl oor
1
with / " (13 mm) reinforced lip and
2
heavy gauge galvanized steel walls.
NSF approved for pre-packaged and
bottled product.
3" (77 mm) diameter stainless steel
insulated beer column. Cold air is
channeled directly into beer column
to reduce foaming and maximize draft
beer profi ts.
Positive seal doors.
"Low-E", double pane thermal glass
door assembly with extruded aluminum
frames. The latest in energy effi cient
technology.
Patented intergrated door light (IDL)
system on glass door provides brighter,
shadow free illumination.
Entire cabinet structure and solid door
are foamed-in-place using high density,
CFC free, polyurethane insulation.
Specifi cations subject to change without notice.
1
/ " (millimeters rounded up to next whole
8
NEMA
Voltage Amps Confi g.
115/60/1 7.6 5-15P
▲
230-240/50/1 3.0
▲ Plug type varies by country.
AVAILABLE AT:
AIA #
SIS #
number).
Crated
Cord
Weight
Length
(lbs.)
(total ft.)
(kg)
(total m)
7 285
2.1 130
